30 32 34 36 38 40 42 44 46 48
REYQ-P
Modules REMQ8P
REMQ10P
REMQ12P
REMQ14P
REMQ16P
Number of outdoor units
Equivalent horsepower HP
Capacity cooling kW
heating kW
Nominal input cooling kW
heating kW
EER cooling
COP heating
Max. number of connectable indoor units
Minimum capacity index
Maximum capacity index - 130 %
Capacity steps
Dimensions height mm
width mm
depth mm
Weight kg
Casing
Colour
Sound pressure level dB(A)
Sound power level dB(A)
Fan type
air flow rate
Refrigerant name
charge kg
control
Refrigerant oil type
charge l
Compressor type
starting method
Piping connections liquid mm
gas mm
discharge gas mm
pressure equalizer tube
mm
Operation range cooling °CDB
heating °CWB
Power supply W1
Safety devices
1 1
1 1 1
1 1 2 1
1 1
1 2 1 1 1 1 2 2 2 3
2 2 3 3 3 3 3 3 3 3
30 32 34 36 38 40 42 44 46 48
85.0 90.0 95.4 101.0 107.0 112.0 118.0 124.0 130.0 135.0
95 100 107 113 119 125 132 138 145 150
26.6 28.4 27.2 29.4 31.2 33.4 35.8 38.0 40.8 42.6
24.2 25.8 26.5 28.2 30.0 31.8 33.5 35.2 37.1 38.7
3.2 3.17 3.51 3.43 3.43 3.35 3.3 3.26 3.19 3.17
3.93 3.88 4.04 4.01 3.97 3.93 3.94 3.92 3.91 3.88
48 52 55 58 61 64 64 64 64 64
375 400 425 450 475 500 525 550 575 600
975 1,040 1,105 1,170 1,235 1,300 1,365 1,430 1,495 1,560
46 46 36 36 41 41 46 46 51 51
1,680 1,680 1,680 1,680 1,680 1,680 1,680 1,680 1,680 1,680
1,240 + 1,240 1,240 + 1,240
930 + 930 + 1,240 930 + 930 + 1,240 930 + 930 + 1,240 930 + 930 + 1,240 930 + 1,240 + 1,240 930 + 1,240 + 1,240 1,240 + 1,240 + 1,240 1,240 + 1,240 + 1,240
765 765 765 765 765 765 765 765 765 765
334 + 334 334 + 334 204 + 254 + 334 204 + 254 + 334 254 + 254 + 334 254 + 254 + 334 254 + 334 + 334 254 + 334 + 334 334 + 334 + 334 334 + 334 + 334
painted galvanised steel
ivory white
63 63 63 64 64 65 64 65 65 65
83.0 83.0 83.0 84.0 84.0 85.0 84.0 85.0 85.0 85.0
propeller fan
230 + 230 230 + 230 180 + 185 + 230 180 + 200 + 230 185 + 200 + 230 200 + 200 + 230 185 + 230 + 230 200 + 230 + 230 230 + 230 + 230 230 + 230 + 230
R-410A
11.7 + 11.7 11.7 + 11.7 8.2 + 9.0 + 11.7 8.2 + 9.1 + 11.7 9.0 + 9.1 + 11.7 9.1 + 9.1 + 11.7 9.0 + 11.7 + 11.7 9.1 + 11.7 + 11.7 11.7 + 11.7 + 11.7 11.7 + 11.7 + 11.7
electronic expansion valve
synthetic ether oil
14.9 15.0 15.7 15.9 17.9 18.1 20.1 20.3 22.4 22.5
hermetically sealed scroll compressor
soft start
19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1
34.9 34.9 34.9 41.3 41.3 41.3 41.3 41.3 41.3 41.3
28.6 28.6 28.6 28.6 34.9 34.9 34.9 34.9 34.9 34.9
19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1
-5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43 -5 ~ 43
-20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5 -20 ~ 15.5
3~, 50Hz, 380-415V
HPS, fan motor overcurrent protector, inverter overload protector, overcurrent relay, PC board fuse
p. 37
Notes: • Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19°CWB • outdoor temperature: 35°CDB • equivalent refrigerant piping: 7.5m • level difference: 0m
• Nominal heating capacities are based on: indoor temperature: 20°CDB • outdoor temperature: 7°CDB/6°CWB • equivalent refrigerant piping: 7.5m • level difference: 0m
