COMPONENTS LIST

COOLER INSTALLATION

MOUNTING HOLES LOCATION

Cooler X1

Spring Nut X4

Insulation Pad X4

TIM X1

43mm

80mm

53mm

55mm

43mm Mounting holes

NVIDIA GeForce GT 240

NVIDIA Geforce 8500/8600/7300/7600

/6000(Except 6600 AGP Series)

AMD Radeon HD 6700（6770/6750）

ATI Radeon HD 5700（5770/5750）/5670

ATI Radeon HD 2400/2600 Series

ATI Radeon X1600/X1650 Series

53mm Mounting holes

NVIDIA GeForce GTX 550 Ti

NVIDIA GeForce GTS 450/GTS 250

NVIDIA GeForce 9800 Series

NVIDIA GeForce 8800GTS/8800GT

NVIDIA GeForce 9600GT/9500GT/9400GT

NVIDIA GeForce 7950/7900/7800/7600/6800

ATI Radeon HD 5500 Series/ 4800 Series/4700

Series4600 Series/3800 Series/ 3600 Series

ATI Radeon HD 3450

ATI Radeon X1900/1950/X1800

55mm Mounting holes

NVIDIA GeForce FX 5700/5600 Series

NVIDIA GeForce FX 5200/5500 Series

NVIDIA GeForce 4 MX Series

ATI Radeon X1300 Series

ATI Radeon X Series

ATI Radeon 9000Series（Excep 9550/9600）

80mm Mounting holes

NVIDIA Geforce 7400 Series

NVIDIA Geforce 7600 Series
