38
Turning dial “A” clock-wise turns the freezer on, with the green LED “B” and the red LED
“C” switching on. When the freezer reaches the set temperature the red LED will switch
off.
The yellow LED “E” switches on when dial “A” is turned to the “SUPER” position, then the
compressor will work continuously.
Dial “H” adjusts the fridge temperature. At the “0” position the fridge will not work.
Turning the dial “H” clock-wise, turns the fridge on and the green LED “G” switches on
(only if the “A” dial is in a different position from “0“).
CONTROL PANEL (fig.4, fig.4b, fig.13)
When the red LED “C” is on or lit up, the temperature inside the fridge or freezer is not
cold enough.
Reasons for failure:
- appliance has just been switched on
- door left opened or ajar
- fresh food for freezing just placed inside the freezer.
The freezer must always ensure temperatures of -18°C or less.
CAUTION: There is no correlation between the numbers shown on the thermostat dial (A)
and the temperatures displayed on the 4 green lights (D).
CONTROL PANEL (fig. 12)
Thermostat "A" controls fridge and freezer.
On position "0" both fridge and freezer do not operate.
By turning the thermostat knob clockwise, the appliance operates and green light "B"
lights up.
CONSERVATION
Some models feature a storage area above the top refrigerated shelf. This area must be
used as a two star compartment as shown on the appliance. The maximum performance
of conservation is obtained by removing all the crispes but lower one.
The symbol shows that frozen products can be stored for a long time and that
fresh foods can be frozen.
Conservation time are closely connected with maintaining the correct temperature, thus
any changes will affect the length of time it can be conserved.
In the case of a power cut do not, under any circumstances, open the door or the lid. The fro-
zen foods will remain wholesome for 10-12 hours. For longer periods the food should be wrap-
ped in special foodstuff paper and preferably put into a refrigerator or, at least in a cool place.
In this case it is advisable to eat the food within 24 hours or to cook it and then to re-freeze it.
FREEZING
The maximum perfomance of freezing is obtained by removing all the crispes but the
lower one.
Fridge Freezer with control panel (fig. 2, fig. 4, fig. 4b & fig. 13)
Before freezing fresh food you should transfer food already frozen in the top compartment
to the compartments below, making room for the fresh produce.
24 hours before freezing food follow the instructions below:
Control panel (fig. 4 – fig. 4b)
To activate the quick freezing function push button “F” for at least 4 seconds, the yellow
LED “E” will switch on to indicate that the quick freezing process has begun. This stage
will stop automatically after 50 hours, restoring the appliance to the previous settings (the
yellow LED will turn off). If you would like to stop the super freezing process before this
time you have to push button “F” for more than 4 seconds.
❋
❋
