20
PRIME/PRO/TUF GAMING X570 Series BIOS Manual
RttNom
Conguration options: [Auto] [Rtt_Nom Disable] [RZQ/4] [RZQ/2] [RZQ/6] [RZQ/1]
[RZQ/5] [RZQ/3] [RZQ/7]
RttWr
Conguration options: [Auto] [Dynamic ODT Off] [RZQ/2] [RZQ/1] [Hi-Z] [RZQ/3]
RttPark
Conguration options: [Auto] [Rtt_PARK Disable] [RZQ/4] [RZQ/2] [RZQ/6] [RZQ/1]
[RZQ/5] [RZQ/3] [RZQ/7]
MemAddrCmdSetup
Conguration options: [Auto] [0]-[63]
MemCsOdtSetup
Conguration options: [Auto] [0]-[63]
MemCkeSetup
Conguration options: [Auto] [0]-[63]
MemCadBusClkDrvStren
Conguration options: [Auto] [120.0 Ohm] [60.0 Ohm] [40.0 Ohm] [30.0 Ohm] [24.0
Ohm] [20.0 Ohm]
MemCadBusAddrCmdDrvStren
Conguration options: [Auto] [120.0 Ohm] [60.0 Ohm] [40.0 Ohm] [30.0 Ohm] [24.0
Ohm] [20.0 Ohm]
MemCadBusCsOdtDrvStren
Conguration options: [Auto] [120.0 Ohm] [60.0 Ohm] [40.0 Ohm] [30.0 Ohm] [24.0
Ohm] [20.0 Ohm]
MemCadBusCkeDrvStren
Conguration options: [Auto] [120.0 Ohm] [60.0 Ohm] [40.0 Ohm] [30.0 Ohm] [24.0
Ohm] [20.0 Ohm]
CLDO VDDP voltage
Conguration options: [Auto] [700]- [66234]
