21169180
SW-Tank
Pos.
Art.Nr.
Stück
Bezeichnung
Description
1
21169100 1 SW-Tank recovery tank
2
20670900 1 Tank-Schraubdeckel screwed lid
3
20557700 2 Toolflex-Halterung 20-30mm tool support
4
20193000 4 Zylinderschraube M 6x10 Zn cilindrical-head screw
5
21174000 1 Fitting fitting
6
21058835 1 Prefilter und Schwimmer prefilter-floater
7
21058600 1 Prefiltertopf suction box
8
21074800 1 Fitting gerade fitting
9
20048300 2 Blechschr.Li C 2,9x6,5 VA screw 2,9x6,5
20063400 1 O-Ring 25x2 O-ring
21058700 1 Prefilterdeckel cover
21075201 1 Rundschnurring D2/110 seal
21061600 1 Prefilter prefilter
21058800 1 Schwimmerkorb float body
21058900 1 Tischtennisball D40 ball
21174100 1 Grobschmutzkorb waste container
21175500 1 Befestigungswinkel mounting bracket
21252300 1 Ablaufschl.m.Ablaßstutzen drain hose
20219700 Schlauchschelle W432-50/9 hose clamp
20643634 1 Saugschlauch NW38 L=610 suction hose
21169900 1 Luftführung air conduct
50644901 0,620m Zellgummiband 12x3 seal
20193000 4 Zylinderschraube M 6x10 cilindrical-head screw
21173800 2 Scharnier PA links hinge PA left
20636900 12 Senkschraube M 6x12 V2A countersunk screw
21169200 1 SW-Deckel tank cover
50798500 1,1m Dichtprofil 8564/00M001 band sealer
20978400 2 Deckelbolzen rechts lid bolt, right
20816200 1 Schraube KA 50x16 EJ schw screw KA 50x16 EJ black
20070000 1 6-Kantmutter M 6 STOPP VA hex. nut M 6
20230500 1 Saugaggregat 24/350 2-stuf suction motor
20158800 1 Dichtung D60/D38x7 gasket
20110600 1 Gummiring L-Form gasket
21169800 1 Distanzring spacer
20567600 4 Zylinderschraube M 6x55 VA screw M 6x55
20938400 3 Gewindestange M6x100 screwed bar M6x100
20002000 6 6-Kantmutter M 6 VA hex. nut M 6
20937700 1 Schalldämmung sound insulation
20937600 1 Schalldämmhaube cap for sound insulation
20070000 3 6-Kantmutter M 6 STOPP VA hex. nut M 6
20000700 3 Scheibe 6,4x12,0x1,5 VA washer 6,4
20975500 1 Schalldämpfer sound insulation
20815400 1 Schlauchschelle W450-70/9 hose clamp
21169300 1 Chemietank tank for detergent
70113000 1 Aufkleber ARA 66│BM 70 label
21169700 2 Scharnierplatte plate
20200000 1 Stopfen Ø12 stuff
20159700 1 Griffknopf M5/D25 button M5xØ25
21173900 1 Rastbolzen locking pin
21246200 1 Gewindebuchse screw socket
20682400 1 6-Kantmutter M10 STOPP VA hex. nut M10
20054000 1 Druckfeder D6,1x29-D0,8 tension spring
20151900 1 Zylinderschraube M 6x12 VA cylindrical-head screw
20113000 1 Scheibe 6,4x17,6x1,5 VA washer
20054500 1 Scheibe 10,5x18,0x1,6 VA washer
21173700 1 Schraubdeckel Chemietank screwed lid
7
