SiEBE04-507 Outdoor Unit
Removal Procedure 169
2
The partition plate has
a hook on the lower
side. Lift and pull the
partition plate to
remove.
When reassembling, fit the
lower hook into the bottom
frame.
Step
Procedure Points
(R3270)
Hook
