SiENBE04-507A Outdoor Unit
Removal Procedure 193
2
The partition plate has
a hook on the lower
side. Lift and pull the
partition plate to
remove.
When reassembling, fit the
lower hook into the bottom
frame.
Step
Procedure Points
Hook
