6
4.3 When processing is finished
• When processing is finished, unplug the machine from
the power supply, remove weights, raise the brush
head and remove the drive backs, and abrasive discs
or pads. Wipe over the machine with a damp cloth.
• Remove and clean finishing discs and polishing pads.
• Empty the solution tank by pulling the feed hose off the
brush head and directing the hose over a suitable
drain.
• IMPORTANT - Dispose of unused cleaning solution in
accordance with the manufacturer’s directions and
local authority regulations.
• Flush out solution tank with clean water.
4.4 Scrubbing and stripping
• Fit brushes or drive discs and pads suitable for the
surface to be cleaned.
• Fill the solution tank with clean water and an
appropriate measure of detergent.
• Before starting the machine release a liberal amount of
cleaning solution from the tank to the floor. The flow of
solution from the tank is controlled by lifting the left
hand lever. Releasing the lever stops the flow.
• Proceed to operate the machine in the normal manner,
releasing more cleaning solution from time to time as
required.
• Dirty water should not be allowed to accumulate on the
floor; it should be removed to prevent dirt from settling.
We suggest using a wet & dry vacuum for this
purpose.
• When scrubbing/stripping is complete, unplug the
machine from the power supply, empty the solution
tank and clean and dry the machine.
• IMPORTANT - Dispose of unused cleaning solution in
accordance with the manufacturer’s directions and
local authority regulations.
4.5 Bonnet Spraying
• Fill tank with warm water.
• Add Bonnet spray cleaner (D80) in proportions quoted.
• Rotate machine head vertically.
• Place brush and 2 drive backs.
• Place clean bonnets on drive backs.
• Rotate head horizontally ensuring bonnets remain
attached.
• Start cleaning operation by:
o Turning on the machine
o Turning on pump switch – Note the switch has two
positions – momentary pulse and continuous spray.
o Walk forward spraying carpet ensuring only a light
coverage – do not soak the carpet.
o Check the bonnets regularly and change when dirty.
4.6 Polishing and buffing
• Fit drive discs and pads suitable for the surface to be
polished.
• Ensure the floor is clean and dry.
• Walk slowly behind the machine, overlapping each
pass to ensure an even finish.
• Do not keep the machine rotating on one spot for more
than 10-15 seconds, as this could cause overheating
and damage the floor surface.
• Should the machine start to vibrate, or resist the
buffing action on the floor, check the cleanliness of the
pads. When dirty on one side the pad may be
reversed.
4.7 Cimex-Encap Carpet Cleaning
• IMPORTANT - Model CR38 (620rpm) is not suitable
for use on carpets.
• Fit pad drives and pads or shampoo brushes.
• Fill the solution tank with clean water and an
appropriate measure of Cimex-Encap™ Low Moisture
solution.
• CAUTION - Before cleaning, test a small area of
carpet with the shampoo solution to ensure it is colour-
fast.
• With the machine running, apply solution to the carpet
until thin white foam is obtained. Do not over-wet the
carpet.
• Carpet will dry to the touch in approx. 1 hour, but allow
overnight drying for full encapsulation process to take
place.
• Encapsulated dirt is simply removed by routine
vacuuming.
4.8 When cleaning is finished
• When cleaning is finished, unplug the machine from
the power supply, raise the brush head and remove
brushes or pads, and wipe over the machine with a
damp cloth.
• Wash brushes and pads in warm soapy water, rinse
and allow to dry naturally.
• Empty the solution tank by pulling the feed hose off the
brush head and directing the hose over a suitable
drain.
• IMPORTANT - Dispose of unused cleaning solution in
accordance with the manufacturer’s directions and
local authority regulations.
• Flush out solution tank with clean water.
5. Storage
• After use always wipe down and dry the machine, and
remove and clean the drive backs, pads or brushes.
Clean the rotating dust cover (10) and check the
condition of the brush seals (9). The seals should be
cleaned periodically to maintain their effectiveness.
• The solution tank should be emptied and flushed out
with clean water.
• The machine should normally be stored with the
handle in the raised position and the brush head tipped
back. Never leave the brush head resting on the drive
pins.
• Wrap supply cord around the handlebar and cable
winder ensuring that the plug is not trailing on the floor.
• Store the machine in a dry indoor area only.
