3
MODEL RANGE
Indoor units - cooling only
Class 25 35 50 60
Wall mounted Current (R-22) FTK25JAV1NB FTK35JAV1NB FTK50HV1NB FTK60HV1NB
New (R-410A) FTK25AZVMB FTK35AZVMB FTK50AZVMB FTK60AZVMB
Concealed Current (R-22) CDK25HAV1NB CDK35HAV1NB CDK50HAV1NB CDK60HAV1NB
ceiling New (R-410A) CDK25AZVMB CDK35AZVMB CDK50AZVMB CDK60AZVMB
Floor standing Current (R-22)* FVK25KZV1B FVK35KZV1B - -
New (R-410A) - - - -
Flexi type Current (R-22) - - - -
New (R-410A) FLK25AZVMB FLK35AZVMB FLK50AZVMB FLK60AZVMB
Indoor units for multi connection (for more info on indoor units, see chapter 3)
FEATURES OF OUTDOOR UNITS
OVERVIEW
1. Energy saving via the latest Daikin technology
• Swing compressor
• Reluctance DC motor
• PAM control
2. Quiet Operation
• Outdoor unit silent operation
• Night quiet mode
3. Wider operation range
4. Changes for installation and after sales service works.
5. User friendly functions
• Priority room setting
• Cooling / Heating mode lock (Heat pump models only)
6. Improved durability
Indoor units - heat pump
Class 25 35 50 60 71
Wall mounted Current (R-22) FTX25JAV1NB FTX35JAV1NB FTXD50JV1B FTXD60JV1B FTXD71JV1B
New (R-410A) FTX25AZVMB FTX35AZVMB FTX50AZVMB FTX60AZVMB FTX71AZVMB
Concealed Current (R-22) CDX25HAV1NB CDX35HAV1NB CDX50HAV1NB CDX60HAV1NB -
ceiling New (R-410A) CDX25AZVMB CDX35AZVMB CDX50AZVMB CDX60AZVMB -
Floor standing Current (R-22)* FVX25KZV1B FVX35KZV1B - - -
New (R-410A) FVX25AZVMB FVX35AZVMB FVX50AZVMB FVX60AZVMB -
Flexi type Current (R-22) - - - - -
New (R-410A) FLX25AZVMB FLX35AZVMB FLX50AZVMB FLX60AZVMB -
MODEL RANGE
(*) Note : These units are R-410A indoor units which can also be connected to the current inverter multi outdoor units using R-22.
00225•New products•01-12 09-11-2001 11:17 Pagina 4
