Operation manual
7
EBHQ006+008BAV3 + EKCBX/H008BAV3
Unit for air to water heat pump system
4PW64603-1A – 08.2010
Selection and setting of domestic water heating (w)
1 Use the v button to activate domestic water heating (w).
Icon w appears on the display.
2 Use the wi or wj button to display the actual
temperature set point and subsequently, to set the correct
temperature.
The actual temperature set point only appears on the display
after pressing one of the buttons wi or wj. If no button is
pressed for 5 seconds, the temperature set point will
automatically disappear from the display again.
Temperature range for domestic water heating: 30°C to 78°C
3 Press the v button to deactivate domestic water heating (w).
Icon w disappears from the display.
Selecting powerful domestic water heating operation
1 Press
v for 5 seconds to activate powerful domestic water
heating operation.
Icons w and m start flashing.
Powerful domestic water heating is deactivated automatically
when the set point for the domestic hot water is reached.
Selecting quiet mode operation (s)
1 Use the s button to activate quiet mode operation (s).
Icon s appears on the display.
If the controller is set in permission level 2 or 3 (refer to "Field
settings" on page 11), the s button will not be operable.
Selecting weather dependent set point operation (only in
heating mode)
1 Press the ba button to select weather dependent set point
operation.
Icon a appears on the display as well as the shift value. The
shift value is not shown in case it is 0.
2 Use the bi and bj buttons to set the shift value.
Range for the shift value: –5°C to +5°C
Displaying actual temperatures
1 Push the ba button for 5 seconds.
The b icon and the outgoing water temperature are displayed.
The icons
l and = are flashing.
2 Use the
pi and pj buttons to display:
• The outdoor temperature (u icon is flashing).
• The domestic hot water tank temperature (
w icon is
flashing).
• The outgoing water temperature (
= are flashing).
If no button is pressed for 5 seconds, the controller leaves the
display mode.
Schedule timer operation
In schedule timer operation, the installation is controlled by the
schedule timer. The actions programmed in the schedule timer will be
executed automatically.
The schedule timer always follows the last command until a new
command is given. This means that the user can temporarily overrule
the last executed programmed command by manual operation (Refer
to "Manual operation" on page 6). The schedule timer will regain
control over the installation as soon as the next programmed
command of the schedule timer occurs.
The schedule timer is enabled (
p icon displayed) or disabled (p icon
not displayed), by pressing the pr button.
To set up the SCHEDULE TIMER refer to chapter "Programming and
consulting the schedule timer" on page 8.
NOTICE
Remark that pushing the y button has no influence on
the domestic water heating. Domestic water heating is only
switched on or off by means of the v button.
NOTICE
■ Only use the pr button to enable or disable the
schedule timer. The schedule timer overrules the y
button. The y button only overrules the schedule
timer until the next programmed action.
■ If the auto restart function is disabled, the schedule
timer will not be activated when power returns to the
unit after a power supply failure. Press the
pr button
to enable the schedule timer again.
■ When power returns after a power supply failure, the
auto restart function reapplies the user interface
settings at the time of the power supply failure.
It is therefore recommended to leave the auto restart
function enabled.
■ The programmed schedule is time driven. Therefore, it
is essential to set the clock and the day of the week
correctly. Refer to "Setting the clock" on page 5.
■ Manually adjust the clock for summertime and
wintertime. Refer to "Setting the clock" on page 5.
■ A power failure exceeding 2 hours will reset the clock
and the day of the week. The schedule timer will
continue operation, but with a disordered clock. Refer
to "Setting the clock" on page 5 to adjust the clock and
the day of the week.
■ The actions programmed in the schedule timer will not
be lost after a power failure so that reprogramming the
schedule timer is not required.
