Trim frame installation

To install the trim frame, press it to the unit body and push it to fix it in place. This should be done before

installing the front panel; otherwise you are not able to install the trim frame. When the trim frame being

installed, the side with the groove should face down and fixed first.

Installing the front panel

Turn off the power. Insert the right locker on the receiver into the right groove of the panel, and then insert

the left locker into the left groove. Lift the panel and press on the upper right corner of the panel until a click.

Ensure the panel is fixed properly, otherwise error symbols may be displayed or some buttons will not

function.

To detach the front panel

Press OPEN button. When the panel is in horizontal position, push the panel to the left and detach the right

part of the panel from the locker, and then detach the left part.

Anti-theft system

The front panel of this unit can be stored in the included protective case when not in used and carried away

when you leave the vehicle to deter theft.

Switch off the power of the unit. Detach the front panel, then put it to the protective case and take it with

you.

Cautions: The control panel can easily be damaged by shocks. After removing it, place it in a protective case

and be careful not to drop it or subject it to strong shocks.

The rear connector that connects the main unit and the control panel is an extremely important part. Be

careful not to damage it by pressing on it with fingernails, pens, screwdrivers, etc.

Note: If the control panel is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton swab soaked in

isopropyl alcohol to clean the socket on the back of the control panel.
