HE02EIP us$ 4K2K HDMI CAT5 Extender with IR/PoH_70M__

 Extends HDMI and IR signal over one CAT5/5e/6 cable.

 Uncompressed high definition video up to 1080p@60Hz@48bits and 3D and 4K*2K capable.

 Bi-directional IR, support 30-60kHz.

 Max. Data Rate- 10.2Gbps.

 HDMI 1.4 and HDCP compliance.

 Transmission range up to 70M by CAT5e/6 at 1080p@60Hz@24bit.

 Audio support up to LPCM7.1, Dolby TrueHD, DTS-HD MA.

 Support PoH (Power over HDBaseT), no external power required at receiver.

 External power supply included for the Transmitter.

ARC01 HDMI ARC (Audio Return Channel) / Digital Audio Bi-directional Converter

Feature:

 As an ARC decoder/encoder.

 Design to use for AV receiver or TV without ARC function.

 Decode HDMI ARC audio to digital audio.

 Encode digital audio to HDMI ARC output.

 Digital audio support: Coax and optical input/output.

Installation View:

EE01H HDMI EDID Emulator

 Support 4 different EDID function: read, write, emulate, by pass

 Allows the source device to read the selected EDID inform

ation from the unit default or learned EDID

memory.

 Built in rotary switch, support up to 12 sets default EDID setting

 Allow to save 3 sets custom EDID.

 Built in USB port to allow user to write EDID

 Built in Equalizer for reliable signal quality performance.

 Support HDMI 1.4a

 HDCP compliant.

 Support 4K2K@30Hz and 3D capable.
