GRUPAd.o.o.
outdoor1
outdoor2
outdoor3
Oil trap (upright projecting pipe, 200mm high), as the figure:
outdoor1
outdoor2 outdoor3
Below is forbidden (compressor oil will flow into the lowest outdoor).
outdoor1
outdoor2
outdoor3
96
