AQ18TSANSER AS18TSEANXCHAQ18TUBANXAX

AS18TUBANXAX

AS18TUBANXVN

AS18TUBANXAP

1 DB94-01923B ASSY BACK BODY ASSY 1 1 1 1 SA

1-1 DB61-03663A BODY BACK HIPS 1 1 1 1 SA

1-2 DB62-05905A INSULATION-BODY REAR EPS 1 1 1 1 SA

2 DB92-02276A ASSY PANEL FRONT ASSY 1 1 1 1 SA

2-1 DB64-02547A PANEL FRONT HIPS 1 1 1 1 SA

2-2 DB93-10861A ASSY PCB SUB-DISPLAY ASSY 1 1 1 1 SA

2-3 DB90-06117A ASSY COVER DISPLAY ASSY 1 1 1 1 SA

2-4 DB63-02759A FILTER-PRE PP 2 2 2

3 DB92-02277A ASSY GRILLE ASSY 1 1 1 1 SA

3-1 DB64-02557A GRILLE-AIR INLET HIPS 1 1 1 1 SA

3-2 DB64-02551A DECO-GRILLE HIPS 1 1 1 1 SA

DB93-10854C 1 - - - SA

DB93-10854D -

1- -SA

DB93-10854A 1-SA

DB93-10854B 1SA

4-1 DB90-06305B ASSY CASE CONTROL-IN ASSY 1 1 1 1 SA

DB93-10859A 1 - 1 - SA

DB93-10859D - 1 - 1 SA

4-3 DB90-04385A ASSY COVER CONTROL IN SGCC-M,T0.5 1 1 1 1 SA

DB96-11110A 1 1 - - SA

DB96-11110C 11SA

6 DB94-02957A ASSY TRAY DRAIN ASSY 1 1 1 1 SA

6-1 DB63-02134A TRAY DRAIN ABS 1 1 1 1 SA

6-2 DB61-03672A BLADE-V PP 1 1 1 1 SA

6-3 DB66-01562A BLADE-H ABS 1 1 1 1 SA

6-4 DB62-05904A INSULATION-TRAY FR EPS 1 1 1 1 SA

6-5 DB31-00371A MOTOR STEP DC12V,600GF-CM 1 1 1 1 SA

6-6 DB69-00839A CUSHION-TRAY RH EPS 1 1 1 1 SA

6-7 DB63-02135A TRAY-STABILIZER HIPS 1 1 1 1 SA

6-8 DB94-00458D ASSY HOSE DRAIN ASSY 1 1 1 1 SA

7 DB94-00455B ASSY-RUBBER BEARING ASSY 1 1 1 1 SA

8 DB94-01874B ASSY-CROSS FAN ASSY(AS+GF20%) 1 1 1 1 SA

9 DB31-00532A MOTOR FAN 60HZ 1 1 1 1 SA

10 DB97-11240C ASSY COVER TERMINAL ABS 1 1 1 1 SA

11 DB61-03666A HOLDER-PIPE 1 1 1 1 SA

12 DB61-03651B SUPPORT-EVAP RH HIPS 1 1 1 1 SA

13 DB97-02851C ASSY-PLATE HANGER SGCC-M,T0.6 1 1 1 1 SA

14 DB93-11115K ASSY REMOCON ASSY 1 1 1 1 SA

SA/SNANo Code No. Description Specification

Q'TY

ASSY EVAP TOTAL

ASSY

ASSY CONTROL IN

ASSY

4-2

ASSY PCB MAIN

ASSY
