TRANSFORMATION FROM NATURAL GAS TO LPG AND FROM LPG TO NATURAL GAS

1. Turn off gas and electricity of the cooktop. If your cooktop is hot, wait

for cooling down.

2.For injector change, use a screwdriver whose edge is as the Figure 4.

3. As seen in Figure 5, demount burner lid and burner of the cooktop

and ensure visibility of injector.

4. Remove injector by turning as shown in Figure 6 with screwdriver and

replace it with a new one.

5. After that, detach control switches of the cooktop. Make setting by

turning the screw in the middle of gas cocks with a small screwdriver

in the manner shown in the following picture. To adjust ow rate screw,

use a screwdriver having suitable dimension. For LPG, turn the screw

clockwise. For natural gas, turn the screw one time counter clockwise.

At low position, length of normal ame should be 6-7 mm. For the last

control, check out whether ame is open or closed.

Setting of your appliance may differ according to the type of gas cock

used.

GAS BREAKING SAFETY APPLİANCE (FFD)

Against putting out to be taken place as a

result of liquid overow at upper burners, safety

appliance steps in and cut gas immediately.

Figure 4 Figure 5 Figure 6

Figure 7 Figure 8

Figure 9

FFD
