6
EN
Side handle
Fig. A
The side handle (6) can be rotated 360° around
the drill head, enabling safe and comfortable
operation for both left and right-handed users.
• Loosen the handgrip by turning it
anticlockwise.
• Rotate the handgrip to the desired position.
• Retighten the handgrip in the new position by
turning it clockwise.
Exchanging and removing drill bits
Fig. A - B
Before exchanging bits, first remove the
power plug from the wall socket.
Inspect bits regularly during use. Blunt
bits should be re-sharpened or replaced.
Lightly oil the bit shaft before inserting it
into the chuck.
• SDS drills can be inserted by pushing the drill
into the chuck until a click can be heard. If
needed rotate the SDS drill a little to ensure the
keyway in the bit fits the chuck well.
DO NOT slide the locking sleeve (7) to the
rear when inserting bits.
• To remove the SDS drill, slide the locking
sleeve (7) to the rear and remove the SDS drill
while keeping the sleeve (7) in this position.
Setting depth stop
Fig. A
• The depth stop ruler can be added to the
side handle by turning the depth stop knob (9)
counter-clockwise.
• Insert the depth stop ruler (8) through the hole
on the side handle ring.
• Slide the ruler to the desired depth.
• Tighten the depth stop knob (9).
The On/Off switch
Fig. A
• Switch the machine on by pressing the On/Off
switch (2). When releasing the On/Off switch
(2) the machine will turn off.
Variable speed control (3)
Fig. A
The required speed can be preselected with the
thumbwheel. Also during running the rotational
speed can be adjusted.
1 - 2 = low speed
3 - 4 = medium speed
5 - 6 = high speed
Max = maximum speed
The required speeds depends on the material and
can be determined by practical testing.
Function selection switch
In order to avoid damage to the machine,
adjusting the function selection switch (5)
shall only be done when machine is not
running. Fig. C
Fig. D
The correct position of the function selection
switch (5) for each function is shown in the
pictures in fig. D. Always make sure the function
switch clicks in the desired position.
A) Hammer Drilling (with hammer function): for
drilling in masonry such as brick, concrete and
similar material.
B) Chisel angle adjustment: for changing the
angle of the chisel. When set under right angle
switch back to position D. before using the tool.
C) Chipping (chisel function): for chipping and
small demolition jobs.
User tips
Always use the machine with the side handle
firmly anchored in place - you will not only work
with more comfort, you will also work with more
precision.
Caution: drills and chisels can get very hot.
