For current information and details on the device description and specification, as well as connection process,

certificates, warranty and quality issues, see relevant Installation and Operation Manuals available for downloading at

aeno.com/documents. All trademarks and names herein are the property of their respective owners.

the steam mop towards people, animals or plants. Do not let steam come into

contact with devices containing electrical components. This appliance is not

intended for use by children or persons with lack of experience and knowledge

without the supervision. Do not use the steam mop if the power cord is

damaged, contact an Authorized Service Centre for replacement. If the

appliance is damaged, do not disassemble or attempt to repair the appliance.

Do not use the steam mop for cleaning surfaces with a temperature resistance

of less than +100 °C. Use only purified water with no chemicals or detergents

added. Allow the steam mop to cool down completely before disassembling

and cleaning (at least 15 minutes). Do not use the brass brush on sensitive

surfaces, e.g. enamel, acrylics.

Before you begin

1. Unpack the mop and accessories.

2. Open the cover of the water tank (6) on the body of the appliance (4). Fill the

water tank (5) with water using a measuring cup (16). Put the cover (6) back.

Table 1. Function and installation of accessories

Nozzle

Destination

Build

Steam mop

head (10)

Floor cleaning

together with

cleaning cloth (11)

Connect the handle (1) to the extension

tube (2) and attach it to the steam mop

body (4). Slide the body (4) into the mop

head opening (10) as shown in fig. F

Extension

tube (2)

Extension of the

appliance for effective

cleaning of floors and

hard-to-reach areas

Insert the tube (2) with the handle (1) into

the steam mop body (4). Slide the steam

mop body (4) into the steam mop head (10)

as shown in fig. F
