5English

If there is an excessive amount of oil in the mixture, oily emissions from

the muer (not burnt oil) are possible. Mix fuel and oil in a separate clean

container. To prepare the fuel mixture, ll a clean container with half the

amount of fuel to be used. Then add all oil.

Mix (shake) the fuel mixture. Add the remaining half of the fuel. Mix (shake)

the fuel mixture before lling the fuel tank. Always switch o the engine

before fuelling. Clean the area arond the tank cap to prevent dirt from

entering the tank. Mix the fuel well by shaking the container. Open the

fuel tank slowly to relieve possible overpressure. After refueling, carefully

tighten the fuel tank cap. Always move the ground drill at least 3 meters

from the fuel lling area before starting it.

STARTING ENGINE

1.Set the ignition switch to ON.

2. Press the fuel suction button on the carburetor several times so that fuel

ows through the cylinder and into the return pipe.

3. Pull the recoil starter quickly while holding the lever rmly in your hand

and preventing it from snapping back.

4. If you hear the engine start to start, return the choke lever to the RUN

position (OPERATION) (open). Then pull the recoil starter again quickly.

ATTENTION! If the engine does not start, repeat the operation.

OPERATION

Caution: Ground drill is designed for the operation with 1 (density

600...1600 kg/m3) and 2 ( density 1600... 1900 kg/m3) classes of soil. Con-

tinuous working time of the ground drill with 1 class of soil (sand, clay sand,

vegetable soil, peat) doesn’t exceed 5 min. Continuous working time of the

ground drill with 2 class of soil (light loam, sand with crushed stone) is no

more than 3 min. Recommended interval between continuous usage is no

less than 15 min with full stoppage of the engine. It’s forbidden to decline

the ground drill from the axis of drilling more than 3°. Excessive deviation

can lead to the breakage of the gear case parts.

Never try to drill the hole on full depth of the auger bit. Drill step-by-step.

Excessive pressure on the ground drill can lead to the breakage of the gear

case, overheating of the engine and its breakdown. Deep the auger drill

on 20-30 cm and raise it slightly in the hole. Remove earth from the auger

bit. Don’t take out the whole rotating auger bit from the hole. It can lead to

the injury. Don’t speed up if the auger bit is jammed in the ground. It can
