14
English
Symbol Meaning
A sign certifying that the
product complies with es-
sential requirements of the
EU directives and harmo-
nized EU standards�
Step speed controller posi-
tion�
Do not dispose of the power
tool in a domestic waste
container�
DWT
power tool designation
Mixer is intended for miхing powdered building materi-
als, such as lime, cement, mixes for plaster, materials
not containing the solvents, varnishes and similar sub-
stances�
1
Power tool
components
On / off switch
2 Ventilation slots
3 Step speed selector
4 Tool holder
5 Lock-on button
6 Speed selector thumbwheel *
7 Stirrer paddle *
8 Rod *
9 Wrench (22 mm) *
10 Wrench (19 mm) *
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation
of power tool elements
Before carrying out any works on the power tool it
must be disconnected from the mains.
Do not draw up the fastening elements
too tight to avoid damaging the thread.
Mounting / replacement of stirrer paddle (see g. 1)
• Screw the stirrer paddle 7 on the rod 8 and tighten
them with two wrenches 9 (22 mm) (see g. 1.1).
• While holding the tool holder 4 with spanner 10 (19
mm), screw the rod 8 (with the stirrer paddle 7 put on
it earlier) in, and tighten it with spanner 9 (22 mm) as
shown on g. 1.2.
• Disassembly operations do in reverse sequence�
Initial operating
of the power tool
Always use the correct supply voltage: the power sup-
ply voltage must match the information quoted on the
power tool identication plate.
Switching the power
tool on / off
Short-term switching on / off
To switch on, press and hold on / off switch 1, to switch
off - release it�
Long-term switching on / off
Switching on:
Push on / off switch 1 and lock it in the position with
lock-on button 5�
Switching off:
Push and release on / off switch 1�
Design features
of the power tool
Speed selector thumbwheel
Using speed selector thumbwheel 6, you may select the
required stirrer paddle speed (also during operation)�
The required speed is dependent on the material and
can be determined with practical trials�
When operating your power tool at a low speed for a long
time, it has to be cooled down for 3 minutes� To do it, set
a maximum speed and leave your power tool to run idle�
Step speed selector switch
Attention: one can only change the revo-
lutions per minute range after the engine
fully stops.
The rst speed - you can nd the values of
the revolutions per minute range in the tech-
nical specications table.
The second speed - you can nd the val-
ues of the revolutions per minute range in
the technical specications table.
Soft start
Soft start (starting current limitation system) allows for
the soft start of the power tool - the spindle of power
tools spins up gradually without jerks and recoils, and
when the power tool is turned on, this does not impose
an abrupt load on the power network�
Recommendations
on the power tool operation
Stirring various substances
Do not process explosive substances
(for example, highly inammable sol-
vents) and materials with ignition tem-
perature of lower than 21°С. Study the
