21
English
Symbol Meaning
Do not dispose of the power
tool in a domestic waste
container�
DWT
power tool designation
The power tool is intended for dry cutting, grinding and
sanding of metals (and other materials)�
The area of the tool application can be expanded due
to use of additional accessories�
There is a possibility of a stationary installation of the
power tool by use of some special accessories�
1
Power tool
components
Reducer
2 Spindle lock
3 Ventilation slots
4 Protective casing
5 Additional handle
6 On / off switch
7 Body
8 Filter
9 Flange wrench *
10 Mounting lug
11 Casing screw
12 Spindle
13 Flange
14 Disc *
15 Clamping nut
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation
of power tool elements
Before carrying out any works on the power tool it
must be disconnected from the mains.
Do not draw up the fastening elements
too tight to avoid damaging the thread.
Mounting / dismounting / setting-up
of some elements is the same for all
power tool models, in this case specic
models are not indicated in the illustra-
tion.
Additional handle (see g. 1)
Always use the additional handle 5 when operating�
Additional handle 5 may be positioned as deemed
comfortable by the user�
To mount / dismount the additional handle 5, carry out
the operations shown in gure 1.
Protective casing
Always use protective casing 4 when ap-
plying cutting and grinding discs. Opera-
tion of the aforementioned accessories
without protective casing 4 forbidden.
Protective casing 4 should always face the opera-
tor with its closed part.
Mounting / dismounting the protective casing (see
g. 2)
• With a screwdriver (not supplied with the power tool)
release screw 11 and install protective casing 4 onto
the spindle neck, watching that mounting lug 10 comes
into the longitudinal groove of the spindle neck (see
g. 2).
• Turn protective casing 4 into the required position
and tighten screw 11 with a screwdriver (not supplied
with the power tool)�
• When dismounting protective casing 4 repeat the
aforementioned operations in reverse order�
Mounting / replacement of accessories
After mounting accessories of any kind,
make a trial run before commencing op-
eration - start the power tool and let it
work in idle mode for not less than 30
seconds. The operation of accessories with radial
or axial run-out and causing increased vibration of
the power tool is strictly forbidden.
Wearing protective gloves is recom-
mended for mounting / replacing acces-
sories.
Mounting of cutting / grinding disc (see g. 3-4)
• Install ange 13 onto spindle 12 (see g. 3).
• Install one of the aforementioned accessories onto
spindle 12�
• Press and hold spindle lock 2�
• Screw clamping nut 15 onto spindle 12 and tighten it
with ange wrench 9� Attention: at mounting any ac-
cessories over 4 mm thick clamping nut 15 should
be turned over (see g. 4).
• Release spindle lock 2�
Replacing the cutting / grinding disc (see g. 4-5)
• Press and hold spindle lock 2�
• Release clamping nut 15 with ange wrench 9 (see
g. 5).
• Replace the accessory�
• Screw clamping nut 15 onto spindle 12 and tighten it
with ange wrench 9� Attention: at mounting any ac-
cessories over 4 mm thick clamping nut 15 should
be turned over (see g. 4).
• Release spindle lock 2�
Initial operating
of the power tool
Always use the correct supply voltage: the power sup-
ply voltage must match the information quoted on the
power tool identication plate.
