Highlight compensation Supported

Defogging Supported

Networking

Network transmission

Protocols supported by

IPv4

TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP,

HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1

/V2/V3), 802.1x, QoS, DDNS, SMTP, and PPPoE Note: 1. The DDNS

uses the Oray (www.oray.com) scheme. 2. The northbound protocol

needs to adapt to the PPPoE dialup scenario.

Protocols supported by

IPv6

HTTPS，RTP，RTCP，RTSP

Security

Data security Media security

Supports web- or SDK-based media stream encryption; supports a

maximum of two channels of encrypted media streams; supports

encrypted data storage on SD cards

Service security

User rights

Three user roles: administrator, advanced operator, and common

operator

Security mode

User name and password authentication, 802.1X authentication, and

HTTPS digital certificate

Secure boot Supported

Port

Storage port

MicroSD card slot that supports microSDHC/microSDXC; maximum memory card capacity: 256

Network port One RJ45 10M/100M adaptive Ethernet port

Audio port Audio-in portSupported (one-channel built-in MIC)

General Specifications

Power type 12 V DC and PoE (IEEE 802.3af)

Power consumption Maximum: 6 W; typical: 3.3 W

Operating temperature –30°C to +60°C

Operating humidity 5% to 95% (non-condensing)

Surge protection 4 kV

IP rating IP67

IK rating IK10

Weight Net weight 0.8 kg;Gross weight 1 kg

Dimensions Device dimensions φ127 mm x 97 mm;Package dimensions 112 mm x 147 mm x 147 mm
