Defogging Supported
Networking
Network transmission
Protocols supported by
IPv4
TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP,
HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1
/V2/V3), 802.1x, QoS, DDNS, SMTP, and PPPoE Note: 1. The DDNS
uses the Oray (www.oray.com) scheme. 2. The northbound protocol
needs to adapt to the PPPoE dialup scenario.
Protocols supported by
IPv6
HTTPS，RTP，RTCP，RTSP
Security
Data security Media security
Supports web- or SDK-based media stream encryption; supports a
maximum of two channels of encrypted media streams; supports
encrypted data storage on SD cards
Service security
User rights
Three user roles: administrator, advanced operator, and common
operator
Security mode
User name and password authentication, 802.1X authentication, and
HTTPS digital certificate
Secure boot Supported
Port
Storage port
MicroSD card slot that supports microSDHC/microSDXC; maximum memory card capacity: 256
GB
Communication serial
port
RS-485 port
Alarm port 2 input ports and 1 output port
Network port One RJ45 10M/100M adaptive Ethernet port
Audio port
Audio-in portSupported (one-channel LINE IN and one-channel built-in MIC);Audio-out
portSupported (one-channel LINE OUT)
General Specifications
Power type 12 V DC and PoE (IEEE 802.3af)
Power consumption Maximum: 6 W; typical: 3.3 W
Operating temperature –30°C to +60°C (illuminator disabled) –30°C to +40°C (illuminator enabled)
Operating humidity 5% to 95% (non-condensing)
Surge protection 4 kV
IP rating IP67
IK rating IK10
Weight Net weight 0.75 kg;Gross weight 0.935 kg
Dimensions Device dimensions φ127 mm x 97 mm;Package dimensions 112 mm x 147 mm x 147 mm
