16
15 Example applications
(The following images A1 to A6.3 are on a separate enclosed sheet).
A1.1 - A1.4 Stable and non-twisting mitred frame joint.
A2 Very stable block frame joint.
A3 Very stable and non-twisting wood joints in frame and chair construction.
A4.1 - A4.3 Stable, non-twisting and precisely fi tting board joint (mitred).
A5.1 Stable and precisely fi tting board joint (butted).
A5.2 Setting the Domino dowel jointer for board joint (butted), end face dowel hole.
A5.3 Setting the Domino dowel jointer with angle bracket for board joint (butted).
A6.1 Stable and precisely fi tting board joint (centred).
A6.2 Setting the Domino dowel jointer for board joint (centred).
A6.3 Setting the Domino dowel jointer for board joint (centred), end face dowel hole.
ating instructions, or any fault acknowledged at
the time of purchase, is not covered by the war-
ranty. Complaints will only be acknowledged if
the equipment has not been dismantled before
being sent back to the suppliers or to an author-
ised Festool customer support workshop. Store
the operating instructions, safety notes, spare
parts list and proof of purchase in a safe place.
In addition, the manufacturer’s current warranty
conditions apply.
Note
We reserve the right to make changes to the tech-
nical data contained in this information as a result
of ongoing research and development work.
14 EC-Declaration of Conformity
Dowel jointer Serial no.
DF 500 Q 498621, 498622
Year of CE mark: 2006
We declare at our sole responsibility that this
product is in conformity with the following stand-
ards or standardised documents: EN 60745-1,
EN 60745-2-19, EN 55014-1, EN 55014-2, EN
61000-3-2, EN 61000-3-3 in accordance with the
regulations 2006/42/EC, 2004/108/EC.
Dr. Johannes Steimel 06.12.2010
Head of Research, Development and Technical
Documentation
Festool GmbH
Wertstrasse 20
73240 Wendlingen, Germany
REACH for Festool products, their accessories
and consumables
REACh is a European Chemical Directive that
came into effect in 2007. As “downstream users”
and product manufacturers, we are aware of our
duty to provide our customers with information.
We have set up the following website to keep you
updated with all the latest news and provide you
with information on all the materials used in our
existing products: www.festool.com/reach
16 Fault correction
(The following images B1 to B6 are on a separate enclosed sheet).
Fault Cause Adjustment
B1 burns blunt jointer bit use sharp jointer bit
B2 expansion of dowel
hole
jointing depth excessive (greater
than 20 mm) with 5 mm jointing bit
reduce jointing depth
B3 dowel penetrates
workpiece
incorrect workpiece thickness
and/or jointing depth
adapt workpiece thickness and/
or jointing depth
B4 Tears at edge of dowel
hole
excessive feed rate reduce feed rate
