7
VTS reserves the right to introduce changes without prior notice
OMM_HE_SEC_ver 1.7
Terminal
number
Terminal
name
Signal name
Connect to:
Type of
control box
Type of heater
Terminal name on the control box
2
0-10V
Signal
0-10V DC
->
CBX
main
Y1
preheater
AO2
reheater – AHU with DXH
NO1
reheater – AHU with hum.
NO1
reheater – other
NO1
Compact
main
Y1
preheater
AO4
reheater – AHU with DXH
Y1
reheater – AHU with hum.
AO4
reheater – other
AO3
Other
all
0-10V DC
X
Sections quantity
1
2
3
5
St2
Stage 2
->
CBX
main
-
K1.24*
K1.24*
preheater
-
NO3
-
reheater – AHU with DXH
-
K1.24*
-
reheater – AHU with hum.
-
NO3
-
reheater – other
-
NO3
-
Compact
main
-
K1.24*
K1.24*
preheater
-
DO6
-
reheater – AHU with DXH
-
K1.24*
-
reheater – AHU with hum.
-
DO6
-
reheater – other
-
DO6
-
Other
all
-
+24V DC
+24V DC
6
St3
Stage 3
->
CBX
main
-
-
NO6
preheater
-
-
-
reheater – AHU with DXH
-
-
-
reheater – AHU with hum.
-
-
-
reheater – other
-
-
-
Compact
main
-
-
DO5
preheater
-
-
-
reheater – AHU with DXH
-
-
-
reheater – AHU with hum.
-
-
-
reheater – other
-
-
-
Other
all
-
-
+24V DC
*the connection must be made to the contact No. 24 of the pump relay (K1) located in the AHU automation switchboard
Table 10 – group of cables, the connection of which changes with the type of heater and the components used in the AHU
