Монтажная схема Страница: 2

Apach AMK30 Монтажная схема онлайн [2/6] 678068

Apach AMK30 Монтажная схема онлайн [2/6] 678068

1 GUIDA DIN OMEGA H.7MM L=20MM LF1000416020

2 CAVO + SPINA CEE 2P + T LF1010050

3 STRAIN RELIEF + NUT LF1010063

4 CONTROL UNIT FOR SAFETY SWITCHES LF1010080

5 ROUND SENSOR L=2000 SO2020-2400IX LF1010090

6 ROUND MAGNET DIAM.25 LF1010094

7 BOX GW 44207 LF1010704

8 MORSETTO A PETTINE X EQUIPOTENZ. BZ LF1030522050

9 PCB WITH REVERSE TC-ME R3 EQ. LF1033031

10 LABEL FOR 3 PUSH BUTTONS IP/TC LF1041004

11 S/S ON BUTTON W/LIGHT OMEGA 24 V LF1041015

12 S/S OFF BUTTON LF1041018

13 BEARING SP 7205 LF1144504

14 SEAL RING 30-62-7 LF1243001

15 RUBBER FOOT DIAM 40 H=25 LF1433001

16 RONDELLA PLAST. D 5,3X20 H3 ME30-50 LF1443301

17 GUARNIZ.ANTIVIB.RID.MNRV ME30-50 LF1443310

18 BUSH 15X22X28 L=14 LF1495001

19 HANDLE 236-148 M6_COLLECTION TRAY LF1510010

20 MOTORE TC 22 FRZ 380/50 HZ LF1838301

21 SUPP.PIEG.SENS. COD. D.18 SO INOX LF2007022

22 PALA COMPLETA MESCOLATORE IP 30 LF2043018

23 CARENA COMPLETA PRIG ME 30 MP COMP LF2043302

24 COPERCHIO CARENA IP 30 MP COMP LF2043304

25 FRONTALE CHIUS. CAR. IP 30 MP COMP LF2043308

26 CARTER CHIUS. POSTER. IP 30 MP COMP LF2043311

27 OMEGA SUPPORTO MOTORE ME 30 MP COMP LF2043323

28 RID. NMRV 050 B14 I=50 P80 ME 30 MP LF2043340

29 PERNO TRASC. PALA ME 30 MP COMP LF2043344

30 HOLDING FLANGE _ IP 80 BA XP LF2044536

31 FLAT WASHER DIN 125 D 8 IX2125008

32 BLIND NUT DIN 1587 M5 IX21587LC005

33 CAP NUT DIN 1587 M 6 IX21587LC006

34 LINGUETTE DIN 6885/A 8X7X40 IX26885A080740

35 VITE TSPEI DIN 7991 M 8X30 IX27991008030

36 VITE TSP TORX DIN 7991 M 5X20 TX25 IX27991PINTX520

37 WASHER LARGE DIN 9021 D 5X15 IX29021005015

38 WASHER THICK DIN 9021 D 8X32 IX29021008032

39 HEX.SOCKET HEAD CAP SCREW M6 X 20 IX2912006020

40 HEX.SCREW DIN 933 M 6X20 T.F. IX2933006020

41 HEX.SCREW DIN 933 M8 X 20 IX2933008020

42 HEX.NUT DIN 934 M8 IX2934008

43 DADO AUTOBLOCC. ES DIN 982 M 5 ALTO IX2982005

44 VITE POELIERS M 4X10 IX2POEL004010

45 VITE POELIERS M 5X16 IX2POEL005016

46 SCREW POELIERS M6X10 IX2POEL006010

47 RONDELLA PLAST. D 5,3X20 H3 ME30-50 LF1443301

55 CAPACITOR 35UF LF1011035
