Parts
309577Y 29
Ref. Part Description
Qty.
245970 245971 262648 245972 24Y174 18D010
1 240518 ROD, displacement; sst 1
240517 ROD, displacement; sst 1 1
246689 ROD, displacement; sst 1
15H110 ROD, displacement; sst 1
192622 ROD, displacement; sst 1
2 243346 CYLINDER, pump 1
243347 CYLINDER, pump 1 1
245413 CYLINDER, pump 1
17F955 CYLINDER, pump 1
195891 CYLINDER, pump 1
3* 108526 O-RING; PTFE 2
2 2
107098 O-RING; PTFE
2 2
108822 O-RING; PTFE 2
4 248209 SLEEVE, cylinder; sst 1
248210 SLEEVE, cylinder; sst 1 1
248979 SLEEVE, cylinder; sst 1
15H112 SLEEVE, cylinder; sst 1
192619 SLEEVE, cylinder; sst 1
5 195892 HOUSING, valve, intake 1
1 1
195894 HOUSING, valve, intake
1 1
198219 HOUSING, valve, intake 1
7 239932 VALVE, piston 1
24U993 KIT, valve, piston 1 1
240580 VALVE, piston 1
24V125 VALVE, piston 1 1
8* 249770 SPRING, intake ball
1
257842 SPRING, intake 1
255335 SPRING, intake ball 1
9 239922 SEAT, intake; carbide; includes items 10 and
11
1
1
244199 SEAT, intake; carbide; includes items 10 and
11
1 1
240918 SEAT, intake; carbide; includes items 10 and
11
1
192642 SEAT, carbide 1
10* 107079 O-RING; PTFE 1
1 1
108526 O-RING; PTFE
1 1
107098 O-RING; PTFE 1
11* 105445 BALL, intake; sst; 0.5 in. (13 mm) 1 1 1
102972 BALL, intake; sst; 0.875 in. (22 mm)
1 1
107167 BALL, intake; sst; 1 in. (25 mm) 1
12 192624 GUIDE, ball 1 1 1
193027 GUIDE, ball
1 1
193391 GUIDE, ball 1
13* 117450 SEAL, u-cup, piston; UHMWPE 1 1 1
117449 SEAL, u-cup, piston; UHMWPE
1 1
117448 SEAL, u-cup, piston; UHMWPE 1
14* 15B078 BUSHING, piston 1 1
15J197 BEARING, lower
1 1
15B079 BUSHING, piston 1
17F958 BEARING, lowe 1 1
