IM2022
14
4. Turning off
Turn the thermostat knob fully counterclockwise and let the device run in ventilation mode for 3 minutes to
cool the heating elements, then set the operating mode selection knob to position.
ATTENTION!
In order to increase the lifetime of the device, it is recommended to follow the above mentioned instructions
for turning off the device. Turning off the device without cooling the heating elements first can cause
overheating and premature failure of the heating elements.
9. MAINTANANCE
The electric fan heater does not require any consumables for maintenance. In normal use, it does not require
maintenance, but only dusting the fan grilles and monitoring performance. The serviceability of the device is
determined by external inspection, then by turning on and checking the heating of the air flow.
When cleaning the device, do not use abrasive cleaners, as well as products containing alcohol and solvent.
This may damage the coating of the body or the body itself. Use a piece of cloth dampened with water. If the
contamination is heavy, you can use a cloth soaked in soapy water. Before use, the device must be dry.
WARNING:
Before cleaning the device, it must be turned off and disconnected from the power supply.
10. WIRING DIAGRAM
Fig. 3
11. TROUBLESHOOTING
If it is impossible to fix these malfunctions with these methods, contact the authorized service center.
Malfunction
Possible cause
Solution
The device is connected
to the network but doesn’t work
No power
Check whether the power
supply is disconnected from
the device and, if necessary,
connect device to power supply
Defective operation mode switch
Contact an authorized service center
Defective motor
Low heating temperature is set on
thermostat
Set the temperature higher on
thermostat by rotating the handle
clockwise
Faulty contact connection in wiring
scheme of electrical circuit
Contact an authorized service center
or restore reliable
contact connection
