- 20 -
& IOAPIC 24-119 Entries
Enables or disables this function.
Super IO Conguration
& Serial Port
Enables or disables the onboard serial port.
& Parallel Port
Enables or disables the onboard parallel port.
Gigabyte Utilities Downloader Conguration
& Gigabyte Utilities Downloader Conguration
Allows you to determine whether to automatically download and install GIGABYTE Control Center after
entering the operating system. Before the installation, make sure the system is connected to the Internet.
` Thunderbolt(TM) Conguration
This sub-menu provides Thunderbolt related conguration options. This sub-menu appears
only on
motherboards that have an onboard Intel
®
Thunderbolt
™
controller
or motherboards that have a GIGABYTE
Thunderbolt
™
add-in card installed.
& PCIE Tunneling over USB4
Enables or disables PCIE Tunneling over USB4.
& Wake up from Thunderbolt(TM) Devices
Enabled allows the system to wake up from Thunderbolt
™
devices.
USB Conguration
& Legacy USB Support
Allows USB keyboard/mouse to be used in MS-DOS.
& XHCI Hand-off
Determines whether to enable XHCI Hand-off feature for an operating system without XHCI Hand-off
support.
& USB Mass Storage Driver Support
Enables or disables support for USB storage devices.
& Port 60/64 Emulation
Enables or disables support for USB storage devices.
& Mass Storage Devices
Displays a list of connected USB mass storage devices. This item appears only when a USB storage device
is installed.
Network Stack Conguration
& Network Stack
Disables or enables booting from the network to install a GPT format OS, such as installing the OS from
the Windows Deployment Services server.
& IPv4 PXE Support
Enables or disables IPv4 PXE Support. This item is congurable only when Network Stack is enabled.
