- 9 -
Wireless
Communication
Modulem
Intel
®
Wi-Fi 6 AX201 (For PCB rev. 1.0)
Intel
®
Wi-Fi 6 AX200 (For PCB rev. 1.1/1.2)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
Intel
®
Wi-Fi 6E AX211 (For PCB rev. 1.3/1.4)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 5.0 standard.)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
1 x PCI Express x16 slot, running at x1 (PCIEX1_4)
3 x PCI Express x1 slotsj
2 x PCI Express x1 slotsklmn
(The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)
Storage Interface CPU:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2
SSD support) (M2A_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD
support) (M2P_SB)
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD
support) (M2Q_SB)
- 6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
Intel
®
Optane
™
Memory Ready
* System acceleration with Intel
®
Optane
™
Memory can only be enabled on the M.2
connectors supported by the Chipset.
USB Chipset:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2x2 support
- 1 x USB Type-C
®
port with USB 3.2 Gen 1 support, available through the
internal USB header
- 1 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
Chipset+2 USB 2.0 Hubs:
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB headers)
j Only for Z690 UD AC.
k Only for Z690 UD AX.
l Only for Z690 UD.
m Only for Z690 UD AX DDR4.
n Only for Z690 UD DDR4.
Содержание
- Copyright 2
- Disclaimer 2
- Identifying your motherboard revision 2
- Chapter 1 product introduction 3
- Chapter 2 hardware installation 3
- Chapter 3 bios setup 3 3
- Chapter 4 installing the operating system and drivers 5 3
- Chapter 5 appendix 7 3
- Table of contents 3
- 1 motherboard layout 4
- Chapter 1 product introduction 4
- J only for z690 ud ac 4
- K only for z690 ud ax 4
- Z690 ud ac z690 ud ax z690 ud 4
- M only for z690 ud ax ddr4 5
- Z690 ud ax ddr4 z690 ud ddr4 5
- 2 box contents 6
- 1 installation precautions 7
- Chapter 2 hardware installation 7
- 2 product specifications 8
- 2 productspecifications 8
- 3 installing the cpu and cpu cooler 12
- A note the cpu orientation 12
- B installing the cpu 13
- Do not force to engage the cpu socket locking lever when the cpu is not installed correctly as this would damage the cpu and cpu socket 13
- Follow the steps below to correctly install the cpu into the motherboard cpu socket 13
- Be sure to install the cpu cooler after installing the cpu actual installation process may differ depending the cpu cooler to be used refer to the user s manual for your cpu cooler 14
- C installing the cpu cooler 14
- 4 installing the memory 15
- Dualchannelmemoryconfiguration 15
- 5 installing an expansion card 16
- 6 back panel connectors 17
- Displayport 17
- Hdmi 2 port 17
- Ps 2 keyboard mouse port 17
- Sma antenna connectors 2t2r 17
- Usb 2 1 port 17
- Usb 2 1 port q flash plus port 17
- Usb 3 gen 1 port 17
- Audio jack configurations 18
- Line in rear speaker out blue 18
- Line out front speaker out green 18
- Mic in center subwoofer speaker out pink 18
- Please visit gigabyte s website for details on configuring the audio software 18
- Rj 45 lan port 18
- The gigabit ethernet lan port provides internet connection at up to 2 gbps data rate the following describes the states of the lan port leds 18
- The line in jack use this audio jack for line in devices such as an optical drive walkman etc 18
- The line out jack 18
- The mic in jack 18
- The reversible usb port supports the usb 3 gen 2x2 specification and is compatible to the usb 3 gen 2 usb 3 gen 1 and usb 2 specifications use this port for usb devices 18
- The usb 3 gen 2 port supports the usb 3 gen 2 specification and is compatible to the usb 3 gen 1 and usb 2 specification use this port for usb devices 18
- Usb 3 gen 2 type a port red 18
- Usb type 18
- You can change the functionality of an audio jack using the audio software to configure 7 channel audio access the audio software for audio settings 18
- 7 internal connectors 19
- 2 atx_12v_2x2 atx_12v_2x4 atx 2x2 2x4 12v power connectors and 2x12 main power 20
- Connector 20
- The 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 20
- The power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation 20
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 20
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed 20
- 4 cpu_fan sys_fan1 2a 2b fan headers 21
- All fan headers on this motherboard are 4 pin most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 21
- Sys_fan3_pump system fan water cooling pump header 21
- The fan pump headers are 4 pin most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis the header also provides speed control for a water cooling pump please navigate to the bios setup page of gigabyte s website and search for smart fan 6 for more information 21
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from 22
- Connect your addressable led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 of the addressable led strip header incorrect connection may lead to the damage of the led strip 22
- Connector cpu_fan sys_fan1 2a 2b sys_fan3_pump cpu_opt 22
- Cpu_opt water cooling cpu fan header 22
- D_led1 d_led2 addressable led strip headers 22
- Maximum current 2a 2a 2a 2a 22
- Maximum power 24w 24w 24w 24w 22
- No pin 22
- Overheating overheating may result in damage to the cpu or the system may hang 22
- Pin no definition 22
- Pwm speed control 22
- The fan header is 4 pin and possesses a foolproof insertion design most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design 22
- The headers can be used to connect a standard 5050 addressable led strip with maximum power rating of 5a 5v and maximum number of 1000 leds 22
- These fan headers are not configuration jumper blocks do not place a jumper cap on the headers 22
- Voltage speed control 22
- Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices 23
- Chipset supports raid 0 raid 1 raid 5 and raid 10 please navigate to the configuring a raid set page of gigabyte s website for instructions on configuring a raid array 23
- Connect your rgb led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 12v of this header incorrect connection may lead to the damage of the led strip 23
- For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website 23
- Led_c1 led_c2 rgb led strip headers 23
- Sata3 2 3 4 5 6 7 sata 6gb s connectors 23
- The headers can be used to connect a standard 5050 rgb led strip 12v g r b with maximum power rating of 2a 12v and maximum length of 2m 23
- The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standard each sata connector supports a single sata device the inte 23
- To enable hot plugging for the sata ports please visit the bios setup sata and rst configuration webpage of gigabyte s website for more information 23
- Follow the steps below to correctly install an m ssd in the m connector step 1 locate the m connector where you will install the m ssd use a screwdriver to unfasten the screw on the heatsink and then remove the heatsink only the m2a_cpu connector has the heatsink remove the protective film from the thermal pad on the m2a_cpu connector step 2 locate the proper mounting hole based on the length of your m ssd drive if needed move the standoff to the desired mounting hole insert the m ssd into the m connector at an angle step 3 press the m ssd down and then use the included screw to secure it in the connector replace the heatsink and secure it to the original hole remove the protective film from the bottom of the heatsink before replacing the heatsink 24
- M pcie x4 ssd m pcie x2 ssd m sata ssd 24
- M2a_cpu a a 24
- M2a_cpu m2p_sb m2q_sb m socket 3 connectors 24
- M2p_sb a a 24
- M2q_sb a a 24
- There are two types of m ssds m sata ssds and m pcie ssds this motherboard only supports m pcie ssds be sure to verify the type of m ssds you want to use please note that an m pcie ssd cannot be used to create a raid set with a sata hard drive please navigate to the configuring a raid set page of gigabyte s website for instructions on configuring a raid array 24
- Types of m ssds supported by each m connector 24
- F_panel front panel header 25
- 5vdual 26
- F_audio front panel audio header 26
- Head phone detection 26
- Head phone l 26
- Head phone r 26
- Mic detection 26
- No pin 26
- Pin no definition 26
- Sense_send 26
- Some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 26
- Spdif_o s pdif out header 26
- Spdifo 26
- The front panel audio header supports high definition audio hd you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 26
- This header supports s pdif digital output which allows you to connect a s pdif digital audio cable to output digital audio from your motherboard to the supported audio devices for information about connecting the digital audio cable carefully read the manual for your audio devices 26
- Cc1 18 d 27
- D1 18 ssrx2 27
- D1 19 vbus 27
- F_u32 usb 3 gen 1 header 27
- F_u32c usb type 27
- Gnd 14 gnd 27
- Gnd 14 sstx2 27
- Gnd 17 ssrx2 27
- Header with usb 3 gen 1 support 27
- Nc 20 no pin 27
- Pin no definition pin no definition 27
- Rx1 15 rx2 27
- Rx1 16 rx2 27
- Sbu1 19 d 27
- Sbu2 20 cc2 27
- Ssrx1 12 d2 27
- Ssrx1 13 gnd 27
- Sstx1 15 sstx2 27
- Sstx1 16 gnd 27
- The header conforms to usb 3 gen 1 and usb 2 specification and can provide two usb ports for purchasing the optional 3 front panel that provides two usb 3 gen 1 ports please contact the local dealer 27
- The header conforms to usb 3 gen 1 specification and can provide one usb port 27
- Tx1 12 tx2 27
- Tx1 13 tx2 27
- Vbus 11 d2 27
- Vbus 11 vbus 27
- Vbus 17 gnd 27
- Add in card 28
- Add in card connectors 28
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb 2 1 header prior to installing the usb bracket be sure to turn off your computer and unplug the power cord 28
- F_usb1 f_usb2 usb 2 1 headers 28
- From the power outlet to prevent damage to the usb bracket 28
- No pin 28
- Pin no definition 28
- Power 5v 28
- Supports a thunderbol 28
- Thb_c1 thb_c2 thunderbol 28
- The connectors are used to connect to a gigabyte thunderbol 28
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 28
- Usb dx 28
- Usb dy 28
- Chip select 29
- Com serial port header 29
- Data input 29
- Data output 29
- No pin 29
- Pin no definition 29
- Power 3 v 29
- Spi_tpm trusted platform module header 29
- The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 29
- You may connect an spi tpm trusted platform module to this header 29
- Qflash_plus q flash plus button 30
- Rst_sw rst reset button reset jumper 30
- Bat battery 31
- Clr_cmos clear cmos jumper 31
- Cpu cpu status led dram memory status led vga graphics card status led boot operating system status led 32
- Cpu dram vga boot status leds 32
- The status leds show whether the cpu memory graphics card and operating system are working properly after system power on if the cpu dram vga led is on that means the corresponding device is not working normally if the boot led is on that means you haven t entered the operating system yet 32
- Chapter 3 bios setup 33
- Function keys 34
- Startup screen 34
- 1 operating system installation 35
- Chapter 4 installing the operating system and drivers 35
- 2 drivers installation 36
- 1 configuring a raid set 37
- 1 configuringaraidset 37
- Before you begin please prepare the following items 37
- Chapter 5 appendix 37
- Raid levels 37
- Regulatory notices 38
- United states of america federal communications commission statement 38
- Wireless module approvals 40
- Contact us 44
- Gigabyte esupport 44
- To submit a technical or non technical sales marketing question please link to https esupport gigabyte com 44
