& Wake on LAN

Enables or disables the wake on LAN function. (Default: Enabled)

& IOAPIC 24-119 Entries

Enables or disables this function. (Default: Enabled)

& Aperture Size

Allows you to set the maximum amount of system memory that can be allocated to the graphics card.

(Default: 256MB)

& Bios Guard

Enables or disables the Intel

BIOS Guard feature, which protects the BIOS from malicious attacks. (Default:

Disabled)

- 41 -
