59
AMD X670/B650 Series
FCH Common Options
Press [Enter] to congure FCH Common options.
USB Conguration Options
Press [Enter] to congure USB Conguration Options.
USB0 controller enable
Allows you to enable or disable USB0 controller.
USB1 controller enable
Allows you to enable or disable USB1 controller.
USB2 controller enable
Allows you to enable or disable USB2 controller.
USB0 2.0 port enable
Press [Enter] to congure USB0 2.0 port enable options.
USB0 2.0 port 0
Allows you to enable or disable USB0 2.0 port 0.
USB0 2.0 port 1
Allows you to enable or disable USB0 2.0 port 1.
USB1 2.0 port enable
Press [Enter] to congure USB1 2.0 port enable options.
USB1 2.0 port 0
Allows you to enable or disable USB1 2.0 port 0.
USB1 2.0 port 1
Allows you to enable or disable USB1 2.0 port 1.
USB2 2.0 port enable
Press [Enter] to congure USB2 2.0 port enable options.
USB2 2.0 port 0
Allows you to enable or disable USB2 2.0 port 0.
USB0 3.1 port enable
Press [Enter] to congure USB0 3.1 port enable options.
USB0 3.1 port 0
Allows you to enable or disable USB0 3.1 port 0.
USB0 3.1 port 1
Allows you to enable or disable USB0 3.1 port 1.
