Trim frame installation

To install the trim frame, press it to the unit body and push it to fix it in place. This should be done before

installing the front panel; otherwise you are not able to install the trim frame.

Dismantling the unit

1. Make sure the ignition is turned off, and then disconnect the cable from the

vehicle battery’s negative () terminal.

2. Insert your fingers into the groove in the front side of the trim frame

(if installed; apply some effort to detach the frame). Pull the frame to detach it.



3. Insert both of the supplied keys into the slots at the middle left and right

sides of the unit, then pull the unit out of the dashboard.
