IV. Before first use

Get the radiator out of the box and place it on the foam plastic cover. Make sure whether the power cable and

the device were not damaged during the transportation.

Do not operate the radiator if there are any damages.

Attention!

The radiator should always be placed in vertical position to reduce the risk of overheating, fire or electric shock.

V. The installation of roller-legs

1. The roller-legs should be installed before operating the radiator.

2. Turn over the radiator to have access to bottom panel. Make sure that the device is on a flat surface and

there is nothing to scratch the surface of radiator.

3. Screw out the butterfly-shape nuts from the U-shape staple. Install the U-shape staple between the fins

of radiator.

4. Join the U-shape staple and the roller-leg platform.

5. Screw up butterfly-shape nuts.

6. Repeat operation 2, 3,4,5 for the second pair of roller-legs.

VI. The radiator operation

Make sure that the radiator is placed in vertical position to reduce the risk of overheating, fire or

electric shock.

• Before plugging the device in outlet, please make sure, that the power control is in the 0 (OFF) position

and the thermostat control in the MIN (LOW) position.

• Please rotate clockwise the thermostat controller up to «max» position. Use the power regulator to

choose the required temperature: I position – low power, II position – medium power and when two

regulators are switched on – high power mode.

Regulator

position

Power

7 fins

9 fins

11 fins

600 W

800 W

1000 W

900 W

1200 W

1500 W

I+II

1500 W

2000 W

2500 W

Figure 2

Figure 3

Figure 4
