- 14 -

<X> X coordinate position

INT32

<Y> Y coordinate position

INT32

<Z> Z coordinate position

INT32

<ClkOffset> Clock offset of the receiver in Hz, Use 0 for last saved value if available. If

this is unavailable, a default value of 75000 for GSP1, 95000 for GSP 1/LX

will be used.

INT32

<TimeOf Week> GPS Time Of Week

UINT32

<WeekNo> GPS Week Number

UINT16

（ Week No and Time Of Week calculation from UTC time）

<chnlCount> Number of channels to use.1-12. If your CPU throughput is not high enough,

you could decrease needed throughput by reducing the number of active

channels

UBYTE

<ResetCfg> bit mask

0×01=Data Valid warm/hot start=1

0×02=clear ephemeris warm start=1

0×04=clear memory. Cold start=1

UBYTE

Example: Start using known position and time.

＄PSRF101,-2686700,-4304200,3851624,96000,497260,921,12,3*7F

C). Set DGPS Port ID: 102 Set PORT B parameters for DGPS input

This command is used to control Serial Port B that is an input only serial port used to receive

RTCM differential corrections.

Differential receivers may output corrections using different communication parameters.

The default communication parameters for PORT B are 9600Baud, 8data bits, 0 stop bits, and no

parity. If a DGPS receiver is used which has different communication parameters, use this

command to allow the receiver to correctly decode the data. When a valid message is received,

the parameters will be stored in battery backed SRAM and then the receiver will restart using the

saved parameters.

Format:

＄PSRF102,<Baud>,<DataBits>,<StopBits>,<Parity>*CKSUM<CR><LF>

<baud> 1200,2400,4800,9600,19200,38400
