45 cm Built-In Oven Installation and Mounting

Place of use for product must be located before starting installation.

Product mustn't be installed in places which are under the effect of

strong air ow.

Carry the product with minimum two people. Do not drag the product so

that oor isn't damaged.

Remove all transportation materials inside and outside the product.

Remove all materials and documents in the product.

Installation Under Counter

Cabin must match the dimensions provided in gure 2.

A clearance must be provided at the rear part of the cabin as indicated

in the gure so that necessary ventilation can be achieved.

After mounting, the clearance between lower and upper part of the

counter is indicated in gure 5 with "A". It's for ventilation and shouldn't

be covered.

Installation In An Elevated Cabinet

Cabin must match the dimensions provided in gure 4.

The clearances with the dimensions indicated in the gure must be provided

at the rear part of cabin, upper and lower sections so that necessary

ventilation can be achieved.

Installation Requirements

Product dimensions are provided in the gure 3.

Furniture surfaces for mounting and mounting materials to be used

must have a minimum temperature resistance of 100 °C.

Mounting cabin must be secured and its floor must be plane for product

not to tilt over.

Cabin floor must have a minimum strength that would handle a load of

60 kg.

Placing and Securing the Oven

Place the oven into the cabin with two or more people.

Ensure that oven's frame and front edge of the furniture match uniformly.
