18
REMOTE CONTROL
1
3
4
5
6
7
8
9
10
2
1 Auto Clean button 6 Suction power selection button
2 Forward/Reverse Buttons 7 Dock back button
3 Left/Right Buttons 8 Start/Pause button
4 Spiral mode button 9 Row mode button
5 Corner cleaning mode button 10
Call button for the robot vacuum
cleaner
3. SCOPE OF SUPPLY
– Robot vacuum cleaner - 1 pc.
– Dust collector - 1 pc.
– Remote control - 1 pc.
– Brush for cleaning the filter - 1 pc.
– Microfiber for wet cleaning - 1 pc.
– User manual - 1 pc.
– Docking station - 1 pc.
– Charger - 1 pc.
– Left brush - 1 pc.
– Right brush - 1 pc.
– HEPA filter - 2 pcs.
4. OPERATION
4.1. BEFORE STARTING WORK
1. Connect the power supply cable to the docking station, wind the excess length
of the cord into the compartment at the base of the station (Fig. 1).
2. Place the docking station on a flat surface against a wall. Then connect the
station to the mains.
3. Do not install the station in places exposed to direct sunlight.
4. Install the side brushes: align the left and right brushes with the marks on
the bottom cover of the appliance (Fig. 2). Insert the side brushes until you
hear a click.
Fig. 1 Fig. 2
NOTE: Make sure there is at least 1 m of free space
around the docking station on the sides and at least 2 m
at the front.
When installing, make sure that the power cord does
not lie on the floor. Otherwise, the robot cleaner may
catch it and disconnect the station from the network.
The charging indicator will be on while the station is connected to the network.
4.2. CHARGER
1. Turn on the instrument power (button 7)
2. Press START/PAUSE/CHARGE button (
)
3. Press the
button twice to turn on the charging function
Indicator light (on docking station)
– Blue: The battery is fully charged.
– Flashing red: Battery is charging (<80 %).
– Flashing blue: Battery is charging (>80 %).
– Purple: Searching for a docking station.
– Red: Error or low battery.
Two charging modes
1. Charging the battery from the docking station:
– Turn on the power.
– If the blue indicator flashes, press the button twice to automatically
recharge.
– If the red indicator flashes, place the device in the docking station manually.
2. Charging directly from the AC adapter:
– Connect the adapter to the charging socket of the device.
– Press the power button.
NOTE: The device will not start working until it is sufficiently charged. Place
the device on the docking station and it will automatically activate when there
is sufficient charge. The instrument can only turn on automatically when the
battery is ≥20 % charged. The front of the instrument should be facing the
docking station so that the contacts on the docking station are touching the
wireless charging receiver. The distance from the front of the instrument to the
docking station should be approximately 2 cm.
5. OPERATING PROCEDURE
1. Turn on the power
2. Press the
button to start working
3. During operation, press the
button once to pause operation
NOTE:
– The Robot Cleaner is NOT SUITABLE for picking up liquids.
– For wet cleaning, wet the microfiber and attach it to the bottom of the case.
– If the battery charge is below 20 %, the vacuum cleaner will not start. Charge
the battery before cleaning.
– If the battery charge falls below 20 % during operation, the instrument will
automatically return to the docking station to recharge.
– Before starting work, remove all wires from the floor (including the power
cord of the docking station) to prevent disconnection or damage to household
appliances or other objects.
CHARGER
Automatic charging: In the pause mode, press the
button twice, the
instrument will automatically return to the docking station. If the battery charge
falls below 20 % during operation, the instrument will automatically return to
the docking station.
Manual charging: press the recharge button (7) on the remote control, the device
will automatically recharge.
NOTE: if the instrument cannot find the docking station, place the instrument on
the docking station manually.
