11. SETTINGS MENU

11.3.4 FILTER

Here you ﬁnd the MIDI ﬁlter related settings. Use LEVEL/DATA to browse and change the settings.

RCV NOTE will when active, make it possible to play Model:Samples using an external MIDI keyboard

or controller.

RCV CC will when active make it possible to control Model:Samples parameters from an external MIDI

device sending CC/NRPN data.

ENCS controls whether the TRACK PARAMETER, FX PARAMETER and LEVEL/DATA knobs sends

MIDI data or not.

• INT, the knobs only aect the Model:Samples and does not send any MIDI data.

• I+E, the knobs aect the Model:Samples and also send MIDI data to external devices.

If ENCS is set to INT, the encoders will not send MIDI to external devices even if the

track is set to send MIDI out. For more information, please see “8.4.2 MOUT” on page

23.

11.4 AUDIO

In this menu, you specify audio-related settings for the Model:Samples.

11.4.1 HP MAX

The parameter sets the limit of the Headphones volume. This setting is useful if you want to have dier-

ent volume settings for MAIN out and HEADPHONES OUT, for example to protect your ears and your

headphones if you want to turn up the MAIN OUT volume really loud. You can see the HP MAX setting as

a little headphones symbol when you turn the MAIN VOLUME knob.

11.4.2 INT OUT

Sets if Model:Samples sends audio to the MAIN OUT and HEADPHONES OUT or not.

OFF sends no audio.

AUT sends audio unless you are sending and receiving audio over USB. If so, the Model:Samples

detects this and sends no audio to MAIN OUT and HEADPHONES OUT.

ON sends audio.

11.4.3 TRK OUT

Sets if the separate tracks sends audio to the MAIN OUT and HEADPHONES OUT or not. Use the [T1–

T6] pads to toggle the tracks on and o.
