12
1202VLZ4
1202VLZ4
18. Power Connection
Justincaseyoulosethecordprovidedwiththe
1202VLZ4,itspowerjackacceptsastandard3-prong
IECcordlikethosefoundonmostprofessional
recorders,musicalinstruments,andcomputers.
WARNING:BeforepluggingtheACpower
cordintothe1202VLZ4,makesurethat
thevoltageselector[20]slideswitchis
settothesamevoltageasthelocalACmainssupply.
WARNING:Disconnectingtheplug’sground
pincanbedangerous.Don’tdoit.
19. Fuse
The1202VLZ4isfusedforyour(anditsown)
protection.Ifyoususpectablownfuse,disconnect
theACmainspowercord,pullthefusedrawerout
(locatedjustbelowthecordreceptacle)andreplace
thefusewitha500mA(0.5amps)SLOBLO5x20mm,
availableatelectronicsstoresoryourdealer.Usea
250mAfuseifthelocalvoltageis220-240VAC.
Iftwofusesblowinarow,somethingisverywrong.
Pleasecallourtoll-freenumber1-800-898-3211from
withintheU.S.(orthedistributorinyourcountry)and
ndoutwhattodo.
20. Voltage Selector
WARNING:BeforepluggingtheACpower
cordintothe1202VLZ4,makesurethatthe
voltageselector[20]slideswitchissettothe
samevoltageasthelocalACmainssupply.Onlyslide
thevoltageswitchwiththepowercordunplugged.
Useaatheadedscrewdrivertoslidetheswitch
ifneeded.Theswitchallowsyoutousethemixer
indifferentcountriesandvoltages,meetinteresting
peoplefromothercultures,andentertainthemwith
youruniqueblendofRockabillyFunkadeliaThrash
Metal.
21. Power Switch
Pressthetopofthisrockerswitchinwardstoturnon
themixer.ThepowerLEDonthetopsurfaceofthemix-
erwillglowwithhappiness,oratleastitwillifyouhave
themixerpluggedintoasuitableliveACmainssupply.
Pressthebottomofthisswitchtoputthemixerinto
standbymode.Itwillnotfunction,butthecircuitsare
stilllive.ToremoveACpower,eitherturnofftheACmains
supply,orunplugthepowercordfromthemixerandthe
ACmainssupply.
Asageneralguide,youshouldturnthemixeronrst,
beforethepoweramplierorpoweredspeakers,and
turnitofflast.Thiswillreducethepossibilitiesofany
turn-on,orturn-offthumpsinyourspeakers.
22. Phantom Switch
Thisglobalrockerswitchcontrolsthephantompower
supplyforcondensermicrophonespluggedintochannel
mic[1]inputs(seepage8).
Pressthetopoftheswitchinwardstoengage
phantompowertothefourmicinputs.Pressthe
bottomoftheswitchtoturnitoff.
Whenturnedon(oroff),thephantompower
circuitrytakesafewmomentsforvoltagetoramp
up(ordown).Thisisperfectlynormal.Justlikeme.
Oh,andmyimaginaryfriendLazlowhohelpsmewrite
allthemanuals.SayhellotothenicefolksLazlo.
18
19
21 22
20
