DMX512 10 Channels Description

Channel Value Function

1 0-255 Pan

2 0-255 Pan speed

3 0-255 Built-in effect

4 0-255 Built-in effect speed adjustment

5 0-255 Dimmer

6 6-255 Strobe from slow to fast

7 0-255 Red dimmer

8 0-255 Green dimmer

9 0-255 Blue dimmer

10 0-255 White dimmer

Notes:Setting master-slave:Set master machine at Au01,Au02,Au03...Au22 and slave machine

at d001/A001. Just one light could be settled to be master.

Maintenance

Maintenance should be performed every 15-day period, by using a sponge which is dipped with

alcohol, rather than wet cloth or other chemical liquid, to clean the mirror.

Always disconnect from the mains when the device is not in use or before cleaning it.

Warning

Power must be disconnected before maintenance or repair. Do not look at the light source

directly

To prevent or reduce the risk of electrical shock or fire.do not expose this unit to high

temperature/rain or moisture.

Note

Don't separate machine from light source and repair them by yourself , otherwise no good repair

service will be supplied.

Technical Specifications

1. Power supply: 100~240VAC ，50~60Hz

2. Rated power: 90W

3. Lamp spec: 8*8W RGBW 4in1 LED

4. Control signal: DMX512 signal

5. Control mode: Sound Active/ Auto-play/DMX512/Master-Slave

6. Channel:10/38

7. Protection rate: IP20

8. Max operating temperature: 40°
