3English

1.4 The appliance is a ventilating air-cleaning unit equipped with a cross flow fan

(turbine) coming with an aluminium grease filter. Additionally, a odor-absorbing

carbon filter can be supplied. The cooker hood (width 600 mm) is made of carbon

steel sheets with decoration protective powder coating.

1.5 Considering the type of installation above a kitchen range, two operation

modes can be selected:

– air exhaust with corrugated aluminium/plastic air ducts (Ø 150 mm or 120

mm) into a stationary kitchen air shaft (chimney) (Fig. 1);

– recirculation (closed-loop kitchen air circulation) when a cooker hood is not

connected to a chimney; air passes through an aluminium grease filter (supplied

with the hood) and a optional odor-absorbing carbon filter and, finally, returns to

a kitchen (Fig. 2).

1.6 CAUTION! Before installing a cooker hood connect it to the mains power

supply and check all its functions to ensure technical serviceability.

1.7 Only skilled appropriately trained professionals should install, connect and

repair your cooker hood.

1.8 The manufacturer is not responsible for any failure or damage caused by

improper installation, operation or repair.

1.9 The manufacturer reserves the right to make changes in design of the

appliance in order to improve its quality and performance.

1.10 See technical specifications in the User Manual and on the label located in a

housing interior surface (remove a filter to access).

1.11 CAUTION! Install the hood on a wall at 650-750 mm above an electric stove.

As for a gas stove, install the appliance at 750-850 mm above a cooktop (Fig. 1).
