41
Basic Functions
* Appears even if the LCD monitor is set to Standard (No Information).
Zoom powers indicate the combined optical and digital amount of zoom.
These figures appear when the digital zoom is activated.
Exposure Compensation (p. 95)
Long Shutter Mode (p. 96)
White Balance (p. 98)
ISO Speed (p. 109)
Photo Effect (p. 101)
Compression (p. 64)
Resolution (pp. 64,
65)
Low Battery (p. 22)
Metering Mode (p. 94)
Shooting Method (pp. 75, 78)
Flash (p. 66)
Shooting Mode (pp. 68, 81)
Movie Recording (p. 81)
Camera Shake Warning (p. 40)
Spot AE Point Frame ( Mode)
AF Frame (p. 89)
• Stills: Recordable Shots
• Movies (Sec.):
- Recordable Time
- Recorded Time
Zoom Magnification* (p. 45)
*
(Red)*
*
*
Auto Rotate (p. 110)
*
*
Macro/Infinity (p. 71)
AE Lock (p. 92)
FE Lock (p. 93)
AF Lock (p. 90)
*
*
*
Frame Rate (Movie) (pp. 65, 85)
**
My Colors
(p. 102)
*
