2. Divide the line into two equal parts (Fig. 20.3)

and then load the trimmer head by turning the

knob (Fig. 20.4).

WARNING! – Always wear protective

gloves during maintenance operations. Do not

carry out maintenance with the engine hot.

AIR FILTER

Every 8-10 working hours, remove the cover (A,

Fig. 23), clean the lter (C).

BC 22 - 220: Clean with Emak degreaser p/n

001101009, rinse with water and blast dry with

compressed air.

BC 24 - 240: Clean with Emak degreaser p/n

001101009A, rinse with water and blast dry with

compressed air, not too close, blowing from the

inside outwards.

Replace if dirty or damaged. The engine runs

irregularly if the lter is clogged, with consequent

higher consumption and lower performance.

FUEL TANK

Check fuel lter periodically. A dirty lter can cause

dicult starting and lower engine performance.

To clean lter proceed as follows: remove it from

fuel lling hole. Replace it (Fig. 22) if too dirty.

ENGINE

Clean cylinder ns with a brush or compressed

air periodically. Dangerous overheating of engine

may occur due to impurities on the cylinder.

SPARK PLUG

Clean spark plug and check electrode distance

periodically (Fig. 24). Use Champion NGK CMR7H

or of other brand with the same thermal grade.

GEAR HOUSING

Every 30 working hours, remove screw (D, Fig. 8)

on the gear housing and check the quantity of

grease. Do not use more than 10 grams. Use high

quality molybdenum bisulde grease.

Never use fuel for cleaning operations.

CARBURETOR

Before adjusting the carburetor, clean the air lter

BLADE SHARPENING 234 TOOTH

1. Blades are reversible: when one side is no

longer sharp, the blade can be turned over

and used on the other side (Fig. 17).

2. Blades are sharpened using a at single-cut

le (Fig. 17).

3. To maintain the correct balance, le all cutting

edges uniformly.

4. If the blades are not sharpened correctly, this

can set up abnormal vibrations in the machine

and cause the blades themselves to break

ultimately.

BLADE SHARPENING (8 TOOTH

Always check the general condition of the blade.

Correct sharpening permits the maximum

performance of the brush cutter. To sharpen the

teeth, use a le or grindstone and proceed with

light touches, respecting the corners and the

dimensions shown in Fig. 11A.

WARNING! – The wrong type of cutter or

an incorrectly sharpened blade will increase the

risk of kickback. Check mower blades for

deterioration or cracks, and replace if damaged.

WARNING: Never repair damaged

cutting attachments by welding,

straightening or modifying the shape. This

may cause parts of the cutting tool to come

off and result in serious or fatal injuries.

NYLON LINE HEAD

Only use line of the same diameter as the original

to avoid overloading the engine (Fig. 18).

In order to get more line out of the cutting head,

tap it lightly on the ground while working.

Note: Never hit the nylon head against hard spots

such as concrete or stones, it could be dangerous.

Replacing the nylon line on the LOAD&GO

trimmer head (Fig.20)

BC 22 S – BC 22 T - BC 220 S - BC 220 T (Ø 110

mm): cut 4 m of nylon line Ø 2.4 mm.

BC 24 S – BC 24 T - BC 240 S - BC 240 T (Ø 130

mm): cut 8.5 m of nylon line Ø 2.4 mm.

1. Align the arrows and insert the line into the

trimmer head (Fig. 20.1) until it is released from

the opposite side (Fig.20.2).
