Gardena PowerMax 36 E [12/14] Caring for your lawnmower

How to Mow

Your product can be used to cut grass using the

following methods:-

1. Grassbox Fitted:- grass is collected effectively and

compacted into the grassbox. (Q1)

2. Mulch Plug Fitted:- grass cuttings are finely

chopped to return nutrients to your lawn (Q2).

3. Rear Discharge:- Effectively cuts long grass with no

need to empty the grassbox (Q3)

How to Mow

1. Start mowing the edge of the lawn nearest to the

power point so the cable is laid out on the lawn you

have already cut.

2. Mow twice a week during the growing season, your lawn

will suffer if more than a third of its length is cut at one time.

Do Not Overload Your Mower

Mowing long thick grass may cause the motor speed to

drop, you will hear a change in the motor sound. If the

motor speed drops you may overload your lawnmower

which may cause damage. When mowing in long thick

grass a first cut with the cutting height set higher will help

reduce the load. See Cutting Height Adjustment.

Caring for your Lawnmower

Cleaning

• USE GLOVES

• IMPORTANT:- It is very important that you keep your

lawnmower clean. Grass clippings left in any of the

air intakes or under the deck could become a

potential fire hazard.

1. Remove grass from under the deck with brush. (R1)

2. Using a soft brush - remove grass clippings from all

air intakes (R2), the discharge chute (R3) and the

grass box (R4).

3. Using a soft brush, remove grass clippings from the

vision window (R5).

4. Wipe over the surface of your lawnmower with a dry

cloth (R6).

• IMPORTANT:- Never use water for cleaning your

lawnmower. Do not clean with chemicals, including

petrol, or solvents - some can destroy critical plastic parts.

Storing your Lawnmower:

• Loosen the Cam Locks to enable the handles to be

folded over the product (S).

• Store in a dry place where your lawnmower is

protected from damage

At the End of the Mowing Season

1. Replace bolts, nuts or screws, if necessary.

2. Clean your lawnmower thoroughly.

3. Make sure that the electric cable is stored correctly

to prevent damage.

Fault Finding Hints

Fails to Operate

1. Is the correct Starting procedure being followed?

See ʻTo Start your Lawnmowerʼ

2. Is the Power Turned On?

3. Check the fuse in the plug, if blown replace.

4. Fuse continues to blow?

Immediately disconnect from the mains electricity

supply and consult your GARDENA Service Centre.

Poor Grass Collection

1. Disconnect from the mains electricity supply.

2. Clean the outside of the air intakes, the discharge

chute and the underside of the deck.

3. Raise to a higher height of cut. See Cutting Height

Adjustment.

4. If poor collection persists.

Immediately disconnect from the mains electricity

supply and consult your GARDENA Service Centre.

Excessive Vibration

1. Disconnect from the mains electricity supply.

2. Check that the blade is fitted correctly?

3. If the blade is damaged or worn, replace it with a new one.

4. If vibration persists?

Immediately disconnect from the mains electricity

supply and consult your GARDENA Service Centre.

Lawnmower becomes heavy to push

1. Disconnect from the mains electricity supply.

2. In long grass or uneven ground, the height of cut

should be raised to a higher position. See Cutting

Height Adjustment.

3. Check that the wheels and rollers can rotate freely.

4. If problem persists?

Immediately disconnect from the mains electricity

supply and consult your GARDENA Service Centre.

ENGLISH - 3

Grassbox Full Window

• As the grassbox fills up, grass will be visible through

the window (N1).

• When the window/grassbox is full it is time to empty

the grassbox.

Using as a mulcher

1. Your lawnmower is supplied with a mulching plug. (P1)

2. Stop your lawnmower as described in Starting and

Stopping.

3. Lift safety flap and insert the mulching plug into rear

discharge chute, (P2) ensuring it is securely fitted. (P3)

4. The mulching plug prevents grass from being

collected by blocking the collection chute on the

underside of the deck. (P4)

Mulching Plug

To ensure you have a secure connection between the

lawnmower and the extension cable we strongly recommend

you use the following method of attaching the cable:

1. Plug the short connection lead into the socket of the

extension cable. (M1).

2. Form a loop in the end of the extension cable near to

the socket and secure this in the strain relief feature at

the top of the switchbox (M2, M3) This will cause the

socket to hang in a downward direction.

If the short connection lead is damaged, it must be

replaced by the manufacturer, its service agent or

similarly qualified persons in order to avoid a hazard.
