NO. Chinese Name English Name QTY 备注
1 旋耕刀焊接盘 Blade jointing Set 2
2 内六角螺钉 M6x20 Inner Hexangular Screw M6x20 9
3 输出轴衬套 Output Axis Bush 2
4 防尘罩 dustproof Cover 2
5 变速箱壳体R Transmission Case R 1
6 油封 FA25x40x7 Close Oil FA25x40x7 2
7 轴承 30204 Bearing 30204 1
8 轴用挡圈 25 Snap Washer-Shaft 25 2
9 蜗轮 Worm Wheel 1
10 平键 A6 x28 Key A6x28 1
11 输出轴 Output Axis 1
12 卡子2.5 Clip 2.5 2
13 输出轴铆钉 Worm Wheel rivet 2
14 锁紧螺母 M8 Locknut M8 8
15 自攻螺定 St6x12 Sheet Metal Screw St6x12 8
16 U形弯管 U Shape Syphon 1
17 前板 Front Plant 1
18 旋耕刀R Blade R 12
19 螺母 M10 Nut M10 32
20 旋耕刀L Blade L 4
21 螺栓 M10x20 Bolt M10x20 34
22 螺栓 M8x12 Bolt M8x12 2
23 锁紧螺母 M6 Locknut M6 11
24 变速箱壳体L Transmission Case L 1
25 多楔带 7PJ414 Belt 7PJ414 1
26 螺栓 M8x40 Bolt M8x40 4
27 大垫 8 Big Washer 8 6
28 机座 Machine Seat 1
29 聚胺脂垫圈 9 Plastic Washer 9 3
30 汽油机 Gasoline Engine 1
31 螺栓 M8x45 Bolt M8x45 4
32 锁紧螺母 M5 Locknut M5 8
33 护板 Protective Shutter 1
34 螺钉 M5x12 Screw M5x12 8
35 油门拉线 Accelerograph String 1
36 离合器拉线 Clutch String 1
37 L形右弯管 L Shape Right Syphon 1
38 螺母 M8 Nut M8 2
39 旋柄 Revolving Handle 2
40 平垫 8 Washer 8 5
41 卡套 Clip Cover 4
42 卡座 Clip Seat 4
43 线卡 Line Clip 3
44 刹车手把组件 Brake Armguard Hold Assembly 1
45 内六角螺钉 M6x40 Inner Hexangular Screw M6x40 1
46 止转螺栓 M6x60 Stop Turn Bolt M6x60 1
47 手把套 Handle Cover 2
48 油门手把组件 Accelerograph Handle Assembly 1
49 V形弯管 V Shape Syphon 1
50 螺栓 M8x100 Bolt M8x100 2
51 卡簧 Clip Reed 1
52 定位手把 Orientation Handle 1
53 L形左弯管 L Shape Right Syphon 1
54 脚轮调整手把 Wheel Adjustive Handle 1
V500 spare parts list
