DDE V500 II список Руководство по эксплуатации онлайн [2/2] 770545

DDE V500 II список Руководство по эксплуатации онлайн [2/2] 770545

MAIN

55 拉簧 Taut Reed 1

56 螺栓 M8x20 Bolt M8x20 1

57 后支架焊接件 Back Bracket 1

58 脚轮 Wheel 2

59 脚轮套管 Wheel Cover Pipe 2

60 六角发兰面锁紧螺母 M10 Hex Flang Locknut M10 2

61 轮支架 Wheel Bracket 1

62 脚轮调整压块 Wheel Adjustive Block 1

63 旋耕刀外护板 Blade Outer Protective Shutte 2

64 脚轮盖 Wheel Cover 2

65 螺栓 M10x60 Bolt M10x60 2

66 平垫 10 Washer 10 4

67 外齿锁紧垫圈 10 Outer Tooth Washer 10 2

68 变速箱盖板 Transmission Case Cover 1

69 U形固定板左 U Shape Left Fixed Plank 1

70 U形固定板右 U Shape Right Fixed Plank 2

71 六角螺栓 M8x260 Bolt M8x260 2

72 蜗杆 Worm 1

73 销轴 10x60 Pin 10x60 2

74 滚动轴承 6005

Bearing 6005

2

75 隔套 Isolated Cover 2

76 螺栓 M8x60 Bolt M8x60 1

77 螺栓帽 Bolt Cap 1

78 六角法兰面锁紧螺母 M8 Hex Flang Locknut M8 8

79 螺栓 M8x50 Bolt M8x50 1

80 弹簧心轴 Spring Axis 1

81 涨紧轮弹簧 Pulley Tightener Spring 1

82 T型板 T Shape Plank 1

83 变速箱带轮 Transmission Case Pulley 1

84 轴承 608-2Z

Bearing 608-2Z

2

85 螺钉 M5x8 Screw M5x8 2

86 滚动轴承 6004

Bearing 6004

1

87 平垫 5 Washer 5 2

88 弹性圆柱销 5x40

Lock Pin 5X40

1

89 皮带护板 Strap Protective Shutte 1

90 紧定螺钉 M8x12 Fixed Screw M8x12 2

91 发动机带轮 Engine Pully 1

92 涨紧轮隔套 Pulley Tightener Isolated Cover 1

93 CVD50涨紧轮 CVD50 Pulley Tightener 1
