47 5PJ-690 belt 1
48 STE1650-13 Shell side cover 1
49 STE1650-07-03 Chute seat cushion 1
50 STE1650-07-04 chute down seat 1
51 STE1650-03-01 Chute seat 1
52 STE1650-03-02 chute up seat 1
53 STE1650-03-03 Rocker gear 1
54
STE1650-04-03 rocker handle 1
55 STE1650-04-04 Universal box 1
56 STE1650-04-05 Cardan shaft pin 1
57
STE1650-04-01
The lower rocker welding
assembly
1
58 STE1650-04-02 The upper rocker 1
59 STE1650-03-04 snow chute 1
60 STE1650-03-05
snow chute cap 1
61 SW-58 lock handel 2
62 STE1650-11 housing back cover 1
63 STE1650-12 The air outlet sleeve 1
64 STE1650-10-00 The motor fixed block 1
65 STE1650-10-01 Fixed block pad 2
66 STE1650-06-01 brush cover 2
67 STE1650-06-02 brush carrier 2
68 STE1650-06-03
carbon brush 2
69 STE1650-06-04 Brush plate 2
70 STE1650-06-05 motor bracket 1
71 STE1650-06-06 stator 1
72 STE1650-06-07 The motor for front bracket 1
73 STE1650-06-08
Armature (rotor) 1
74 STE1650-06-09 gear case 1
75 STE1650-06-10
The tension pulley spring 1
76 STE1650-06-11 small gear wheel 1
77 STE1650-06-12 big gear wheel 1
78 STE1650-06-13 output shaft 1
79 STE1650-06-14 oil seal 1
80 STE1650-06-15
gear box cover 1
81 STE1650-06-16 belt wheel 1
82 STE1650-06-17 tension pulley bracket 1
83
STE1650-06-18 tension pulley
1
84 SR-10 Circlips for shaft 5
85
SHSS4.2*13
Cross recessed pan head tapping
screws
36
86 NS-L6*28 Saddle bolt 4
87 MHFN6 Six corner flange lock nut 32
88 NS-L8*45 Saddle bolt 4
89
BG-8
Curved spring washers
4
90 HN-8 nut 9
91 NHLN-6 hexagon check nut 1
92
PF-6 Flat washer
1
93
SHSS-4.8*28
Cross recessed pan head tapping
screws
3
