Husqvarna 230 (2009) parts [27/33] 235e 240 240e

Page L 230 CHASSIS & HAND GUARD

235/235e

240/240e

Position Article Quantity Description

Kit

545-066701 1 HANDGUARD

545-127301 1 BOSS SCREW, HANDGUARD

545-061201 1 REAR WALL

530-016064 1 SCREW, MTG REAR WALL

545-075401 1 GROMMET, REAR WALL

545-071401 1 PLATE BAR MOUNTING

545-071301 1 CAP, SPRING HANDGUARD

545-071201 1 SPRING, HANDGUARD POSITION

11 545-230001 1 CHASSIS ASSEMBLY

530-015877 2 BOLT, BAR 11

545-033501 1 ASSY, VENT LINE 11

530-029868 1 PLUG VENT (BRONZE) 11

530-026119 1 CHECK VALVE (DUCK BILL) 11

530-021132 1 LINE-RETURN PURGE 11

530-023877 1 FITTING- FUEL LINE 11

545-061901 1 ISOLATOR FILTER HOUSING 11

545-070801 2 ASSY-OIL/FUEL CAP W/RET. 11

530-015906 2 SCREW M5.28X1.81X16MM PLAS 11

545-033801 1 ASS'Y FRONT ISOLATOR 11

545-063101 1 REAR ISOLATOR SPRING 11

530-095646 1 ASSY- PICK-UP 11

545-078302 1 LINE, FUEL 11

530-015814 1 SCREW CATCHER

530-029850 2 HAIN CATCHER

530-038990 1 SPIKE 32

530-016439 2 SCREW SPIKE 32

530-014381 1 KIT SPIKE
