Page B 230 CHAIN BRAKE ASSY 545 07 11-03

Position Article Quantity Description

530-057950 1 PIN, DOWEL 16

530-057940 1 ASSY, FRONT LINK 16

530-015911 1 M3.83 X 1.81 X 9 PLASTITE 16

530-016415 1 SPRING COMPRESSION 16

530-016110 1 SCREW BAR ADJUSTING 16

530-038593 1 RETAINER PUSH NUT 16

530-015826 1 PIN BAR ADJUST 16

530-015913 1 PIN, BAND RETAINER 16

530-057923 1 BRAKE BAND 16

545-071001 1 COVER, BRAKE BAND 16

530-016064 3 SCP#6-19 X .437 .PL. PAN. 16

530015917 2 NUT, BAR MTG

545-118701 1 DECAL

545-071103 1 CHAIN BRAKE ASS'Y FRT ADJ
