ASRock AMD A320 SAM4 MATX A320M-DVS R4.0 [70/83] Acs enable
![ASRock AMD A320 SAM4 MATX A320M-DVS R4.0 [70/83] Acs enable](/views2/2002896/page70/bg46.png)
X370M-HDV R4.0 / AB350M-HDV R4.0 / A320M-HDV R4.0 / A320M-DVS R4.0
65
English
Determinism Slider
[Auto]
Use default performance determinism settings
cTDP Control
[Auto]
Use the fused cTDP.
[Manual]
User can set customized cTDP.
Fan Control
[Auto]
Use the default fan controller settings.
[Manual]
User can set customized fan controller settings.
PSI
Disable PSI.
ACS Enable
Enable ACS.
PCIe ARI Support
Enables Alternative Routing-ID Interpretation
CLDO_VDDP Control
[Manual]
If this option is selected, user can set customized CLDO_VDDP voltage.
HD Audio Enable
Enable HD Audio.
FCH Common Options
SATA Conguration Options
