OSD Setting

Basic and simple instruction on the control keys.

1) Press the MENU-button to activate the OSD window.

2) Press < or > to navigate through the functions. Once the desired function is highlighted, press the

MENU-button to activate it . press< or >to navigate through the sub-menu functions. Once the desired

function is highlighted, press MENU-button to activate it.

3) Press< or >to change the settings of the selected function. Press AUTO to exit. If you want to adjust

any other function, repeat steps 2-3.

4) OSD Lock Function: To lock the OSD, press and hold the MENU button while the monitor is off and then

press power button to turn the monitor on. To un-lock the OSD - press and hold the MENU button

while the monitor is off and then press power button to turn the monitor on.

Notes:

1) If the product has only one signal input, the item of "Input Select" is disable to adjust.

2) If the product screen size is 4:3 or input signal resolution is wide format, the item of "Image Ratio" is disable to

adjust.

3) One of DCR, Color Boost, and Picture Boost functions is active, the other two function is turned off accordingly.
